10.5 Watt T8 LED; 4Ft; 3500K; Medium Bi Pin base; 50000 Average rated hours; 1700 Lumens; Type B; Ballast Bypass; Single or Double Ended Wiring {ADDITIONAL FINISH INFORMATION: ''White''}
- BULB HOURS:
- 50000
- BULB KELVIN:
- 3500K
- BULB SHAPE:
- T8
- DIAMETER:
- 1.1
- DIMMABLE:
- Non-Dimmable
- HARMONIZED CODES:
- 8539.52.0051
- LENGTH:
- 47.78
- LUMENS:
- 1700L
- SHIP CARTON HEIGHT:
- 1.1''
- SHIP CARTON LENGTH:
- 48
- SHIP CARTON WIDTH:
- 1.1''
- SHIP WEIGHT:
- 0.58
- VOLTS:
- 120V-277V
- WARRANTY:
- 5 YEAR LIMITED - T8 LED BULBS - BALLAST BYPASS
- WEIGHT:
- 0.44
- BEAM SPREAD:
- 210
- BULB ANSI BASE:
- G13
- BULB BASE:
- Medium Bi Pin
- BULB FINISH:
- Gloss White
- CARTON CUBIC FEET:
- 0.0336
- CARTONS PER UNIT:
- 1
- CEC:
- Exempt - Base Not Regulated
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- NEUTRAL WHITE
- CRI:
- 82
- DLC APPROVED:
- YES
- DLC ID:
- PLY6NGSKA26H
- HOUSING COLOR:
- White
- LAMP FILAMENT:
- LED
- LOCATION RATING:
- DAMP
- NSF APPROVED:
- Yes
- OPERATING TEMP:
- -20C (-4F) TO +45C (+113F)
- PACK TYPE:
- SLEEVE
- WATTS:
- 10.5W
- LAMPS:
- YES
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- No
- Standard Style:
- Traditional
- WIDTH:
- 1.10
- WIDTH RANGE:
- 0-15''
- FLUORESCENT EQUIVALENT:
- 25W/28W/32W
- AVAILABLE FOR PURCHASE:
- NO
- NOMINAL LENGTH:
- 48
- QUANTITY AVAILABLE AT MANUFACTURER:
- 9683
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- CCT SELECTABLE:
- NO
- DLC CLASSIFICATION:
- STANDARD
- DLC PRIMARY USE:
- INTERNAL DRIVER/LINE VOLTAGE (UL TYPE B) LAMPS
- FCC COMPLIANT:
- YES
- FEATURE 1:
- SINGLE OR DOUBLE ENDED WIRING
- FEATURE 2:
- ALL-GLASS TUBE
- FEATURE 3:
- DIRECT WIRE 120-277 LINE VOLTAGE
- FEATURE 4:
- DAMP LOCATION RATED
- FEATURE 5:
- DLC LISTED
- FEATURE 6:
- LONG LIFE - 50000 HOURS
- FLICKER FREE:
- YES
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- IOT ENABLED:
- NO
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LENS FINISH:
- GLOSS WHITE
- LENS MATERIAL:
- GLASS
- LONG DESCRIPTION:
- SATCO
- MATERIAL:
- GLASS
- OPERATING FREQUENCY:
- 50/60HZ
- ORDER IN MULTIPLES OF:
- 25
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- SDS SHEET LINK:
- #REF!
- TECHNOLOGY:
- LED
- TUBE GUARD USE:
- YES
- SPECIFICATION NOTES:
- BUILT-IN SHOCK RESISTANT CIRCUIT - (NOT HOT UNTIL BOTH ENDS ARE INSTALLED)
- FINISH:
- WHITE
- BURNING POSITION:
- UNIVERSAL
- More Info {1}:
- ALL-GLASS TUBE
- More Info {2}:
- DAMP LOCATION RATED
- More Info {3}:
- DIRECT WIRE 120-277 LINE VOLTAGE
- More Info {4}:
- DLC LISTED
- More Info {5}:
- LONG LIFE - 50000 HOURS
- More Info {6}:
- SINGLE OR DOUBLE ENDED WIRING
- WATTAGE SELECTABLE:
- NO
- ENCLOSURE RATING:
- 0
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 50W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- EFFICACY:
- 161.90 LPW
- LAMP END TYPE:
- SINGLE ENDED DOUBLE ENDED
- R9 VALUE:
- 9
- ROMANCE COPY:
- SATCO
- SHORT DESCRIPTION:
- 10.5T8/LED/48-835/BP/SE-DE
- TITLE 20 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- 20%
- CA PROP-65:
- LEAD
- IMAGE INFO:
- ''''
- EA LENGTH:
- 48
- SHAP CARTON WIDTH:
- 1.1''
- FLOURESCENT EQUIVALENT:
- 25W/28W/32W
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- BULB DIMMABLE:
- SLEEVE
- START TYPE:
- UTILITY
- STYLE:
- UTILITY
