10.5 Watt; LED Retrofit Downlight; Gimbaled; 120 Volt; CCT Selectable; Black Finish {ADDITIONAL FINISH INFORMATION: ''Black''}
- AVAILABLE FOR PURCHASE:
- NO
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- STYLE:
- UTILITY
- BULB HOURS:
- 50000
- BULB KELVIN:
- WARM TO COOL WHITE
- BULB SHAPE:
- INTEGRATED LED
- BULB TYPE:
- LED
- DIAMETER:
- 7.4
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0091
- LUMENS:
- 800L
- SHIP CARTON HEIGHT:
- 8.07''
- SHIP CARTON LENGTH:
- 4.5
- SHIP CARTON WIDTH:
- 8.25''
- WARRANTY:
- 5 YEAR LIMITED - FIXTURES
- AMPS:
- 0.088A
- ANSI BASE:
- INTEGRATED
- BEAM SPREAD:
- 90
- CA PROP-65:
- LEAD
- CARTON CUBIC FEET:
- 0.1734
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- CALIFORNIA T24 2016 - 2022 JA8 LISTED T20 LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- CALIFORNIA T24 LISTED
- CONNECTION:
- DIRECT WIRED
- CRI:
- 90
- DIMMING TYPE:
- FORWARD PHASE OR REVERSE PHASE OR PHASE SELECTABLE OR TRIAC
- ES UNIQUE ID:
- ESID-2401365
- FCC COMPLIANT:
- YES
- FINISH FAMILY:
- BLACK
- FIXTURE SHAPE:
- ROUND
- IC RATED:
- YES
- INCANDESCENT EQUIVALENT:
- 65W
- IOT ENABLED:
- NO
- LENS FINISH:
- FROST
- LENS MATERIAL:
- POLYCARBONATE (PC)
- MATERIAL:
- POLYCARBONATE (PC)
- NSF APPROVED:
- NO
- OPERATING FREQUENCY:
- 60HZ
- OPERATING TEMPRATURE:
- -20C (-4F) TO +40C (+104F)
- PACK TYPE:
- COLOR BOX
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- REPLACEABLE LIGHT SOURCE:
- NO
- ROHS COMPLIANT:
- YES
- SAFETY LISTING:
- CULUS - CLASSIFIED
- SDS CLASS:
- LED_FIXTURE
- SLOPED CEILING COMPATIBLE:
- NO
- TEMPERATURE (CCT):
- 2700K/3000K/3500K/4000K/5000K
- WEIGHT LB.:
- 0.84
- CEILING:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 1146
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 3.90
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 7.40
- WIDTH RANGE:
- 0-15''
- FEATURE 1:
- DIAMETER: 7.40 INCHES HEIGHT: 3.90 INCHES''
- FEATURE 2:
- BLACK FINISH
- FEATURE 3:
- 90 DEGREE BEAM SPREAD
- FEATURE 4:
- CCT SELECTABLE
- FEATURE 5:
- 800 LUMENS
- FEATURE 6:
- RATED FOR 50000 HOURS
- FEATURE 7:
- SUPERIOR 90 CRI LIGHT QUALITY
- FEATURE 8:
- 5 YEAR LIMITED WARRANTY
- FEATURE 9:
- FCC AND ROHS COMPLIANT
- INDOOR OUTDOOR:
- INDOOR
- LONG DESCRIPTION:
- SATCO'S S11857 10.5 WATT GIMBALED LED DOWNLIGHT IS A SLEEK LIGHTING SOLUTION FOR RESIDENTIAL AND COMMERCIAL APPLICATIONS. ILLUMINATE KITCHENS DINING ROOMS AND OFFICE SPACES WITH THIS CCT SELECTABLE FIXTURE. VERSATILE AND FUNCTIONAL THIS...
- IMAGE INFO:
- ''''
- INCLUDES:
- E26 ADAPTER INCLUDED (S9001)
- MOUNTING PROCEDURE:
- RECESSED DIRECT WIRE
- More Info {1}:
- 5 YEAR LIMITED WARRANTY
- More Info {2}:
- 800 LUMENS
- More Info {3}:
- 90 DEGREE BEAM SPREAD
- More Info {4}:
- CCT SELECTABLE
- More Info {5}:
- DIAMETER: 7.40 INCHES HEIGHT: 3.90 INCHES''
- More Info {6}:
- FCC AND ROHS COMPLIANT
- More Info {7}:
- RATED FOR 50000 HOURS
- More Info {8}:
- SUPERIOR 90 CRI LIGHT QUALITY
- SPECIFICATION NOTES:
- AIMING ANGLE: 22 DEGREES
- WATTAGE SELECTABLE:
- NO
- AIR TIGHT:
- NO
- BAA COMPLIANT:
- NO
- DIMMABLE DOWN TO:
- 100 TO 10 PERCENT
- EFFICACY:
- 76.19 LPW
- JA8 COMPLIANT:
- YES
- ROMANCE COPY:
- SATCO'S 10.5 WATT GIMBALED LED DOWNLIGHT IS A SLEEK LIGHTING SOLUTION FOR RESIDENTIAL AND COMMERCIAL APPLICATIONS. ILLUMINATE KITCHENS DINING ROOMS AND OFFICE SPACES WITH THIS CCT SELECTABLE FIXTURE. VERSATILE AND FUNCTIONAL THIS BLACK ...
- SHORT DESCRIPTION:
- 10.5WLED/DIR/5-6/CCT-SEL/120V/
- TITLE 20 COMPLIANT:
- YES
- TITLE 24 COMPLIANT:
- YES
- TOTAL HARMONIC DISTORTION:
- <20%
- CAN SIZE:
- 5-6 IN.
