60/80/100 Wattage Selectable; LED; Hi-Bay; Type B; Ballast Bypass; Mogul Extended; 5000K; 100V-277V; 250W-300W Metal Halide Replacement {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 50000
- BULB KELVIN:
- 5000K
- BULB SHAPE:
- HI-BAY
- DIAMETER:
- 5.51
- DIMMABLE:
- NON-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0091
- LENGTH:
- 9.130000000000001
- LUMENS:
- 8400L/11220L/14000L
- SHIP CARTON HEIGHT:
- 11.14''
- SHIP CARTON LENGTH:
- 5.91
- SHIP CARTON WIDTH:
- 5.91''
- SHIP WEIGHT:
- 2.91
- VOLTS:
- 100V-277V
- WARRANTY:
- 5 YEAR LIMITED - HI-PRO
- WEIGHT:
- 2.68
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- BEAM SPREAD:
- 120
- BULB ANSI BASE:
- EX39
- BULB BASE:
- MOGUL EXTENDED
- BULB FINISH:
- WHITE
- CARTON CUBIC FEET:
- 0.2252
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- NO
- CEC:
- EXEMPT - BASE NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- NATURAL LIGHT
- CRI:
- 80
- ENCLOSURE RATING:
- BOTH
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- HID EQUIVALENT:
- 175W/250W/320W
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LAMP FILAMENT:
- LED
- LOCATION RATING:
- DAMP
- MATERIAL:
- ALUMINUM / PLASTIC
- MINIMUM COMPARTMENT SIZE:
- LENGTH: 15.75 IN. WIDTH: 14.96 IN.''
- OPERATING FREQUENCY:
- 50/60HZ
- OPERATING TEMP:
- -25C (-13F) TO +50C (+122F)
- PACK TYPE:
- BOX
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 4KV
- TECHNOLOGY:
- LED
- WATTS:
- 60W/80W/100W
- LAMPS:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 159
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 5.51
- WIDTH RANGE:
- 0-15''
- IMAGE INFO:
- ''''
- FEATURE 1:
- WATTAGE SELECTABLE
- FEATURE 2:
- REPLACES HID LAMPS
- FEATURE 3:
- REDUCED SIZE WITH GREATER EFFICIENCY
- FEATURE 4:
- NECK DESIGN FITS MOST FIXTURES
- FEATURE 5:
- ADVANCED INTERNAL THERMAL MANAGEMENT
- FEATURE 6:
- LIGHT WEIGHT
- FEATURE 7:
- DAMP LOCATION
- FEATURE 8:
- WIDE 120 DEGREE BEAM ANGLE
- BURNING POSITION:
- UNIVERSAL
- IOT ENABLED:
- NO
- IP RATING:
- IP64
- More Info {1}:
- ADVANCED INTERNAL THERMAL MANAGEMENT
- More Info {2}:
- DAMP LOCATION
- More Info {3}:
- LIGHT WEIGHT
- More Info {4}:
- NECK DESIGN FITS MOST FIXTURES
- More Info {5}:
- REDUCED SIZE WITH GREATER EFFICIENCY
- More Info {6}:
- REPLACES HID LAMPS
- More Info {7}:
- WATTAGE SELECTABLE
- More Info {8}:
- WIDE 120 DEGREE BEAM ANGLE
- DLC APPROVED:
- NO
- ORDER IN MULTIPLES OF:
- 1
- WATTAGE SELECTABLE:
- YES
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 250W/320W/400W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- EFFICACY:
- 140.00/140.25/140.00 LPW
- ENCLOSED FIXTURE USE:
- YES
- JA8 COMPLIANT:
- NO
- R9 VALUE:
- 12
- ROMANCE COPY:
- SATCO'S NEW HIGH BAY/LOW BAY OFFERS IMPROVED PERFORMANCE ON EVERY LEVEL AND ARE NOW POWER SELECTABLE TO COVER A WIDER RANGE OF APPLICATIONS. REPLACES 175 TO 600 WATT HID TECHNOLOGIES USING 60 TO 150 WATTS OF EFFICIENT SUPERIOR LED LIGHT. ...
- SHORT DESCRIPTION:
- 100W/LED/HID-HB/5K/100-277V
- STYLE:
- UTILITY
- TITLE 20 COMPLIANT:
- NO
- CA PROP-65:
- LEAD
- BULB DIMMABLE:
- NON-DIMMABLE
- EA LENGTH:
- 5.91
- SHAP CARTON WIDTH:
- 5.91''
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- POWER FACTOR:
- 0.99
- TITLE 24 COMPLIANT:
- NO
- DLC CLASSIFICATION:
- HIGH BAY LAMPS
- LENS MATERIAL:
- LED
- START TYPE:
- UTILITY
- DLC ID:
- NO
