LED Adjustable High bay; 110 Watt; 4000K; Integrated Sensor Port; 120-277 Volt {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- STYLE:
- UTILITY
- BULB HOURS:
- 50000
- BULB SHAPE:
- INTEGRATED LED
- BULB TYPE:
- LED
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.11.6020
- LENGTH:
- 26
- LUMENS:
- 15871L
- SHIP CARTON HEIGHT:
- 4.72''
- SHIP CARTON LENGTH:
- 30.12
- SHIP CARTON WIDTH:
- 15.16''
- SHIP WEIGHT:
- 10.12
- WARRANTY:
- 5 YEAR LIMITED - FIXTURES
- WIRE INCLUDED:
- 5.91
- AMPS:
- 0.917-0.397A
- BEAM ANGLE:
- 100
- CARTON CUBIC FEET:
- 1.2472
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- NO
- COLOR TEMPRATURE:
- COOL WHITE
- CONNECTION:
- HARDWIRE
- CRI:
- 80+
- DIMMABLE FUNCTION:
- 0-10V DIMMING ONLY
- DLC APPROVED:
- YES
- DLC CLASSIFICATION:
- PREMIUM
- DLC ID:
- S-1Y9D3K
- DLC PRIMARY USE:
- HIGH-BAY LUMINAIRES FOR COMMERCIAL AND INDUSTRIAL BUILDINGS
- FCC COMPLIANT:
- YES
- FINISH FAMILY:
- WHITE
- FIXTURE SHAPE:
- RECTANGLE
- IC RATED:
- YES
- INDOOR OUTDOOR:
- INDOOR
- IOT ENABLED:
- NO
- IP RATING:
- IP40
- LENS FINISH:
- FROST
- LENS MATERIAL:
- POLYCARBONATE (PC)
- LOCATION RATING:
- DAMP
- MATERIAL:
- ALUMINUM ALLOY
- MOUNTING PROCEDURE:
- CEILING
- OPERATING FREQUENCY:
- 50-60HZ
- OPERATING TEMP:
- -40C (-40F) TO +50C (+122F)
- PACK TYPE:
- BOX
- PHOTOCELL:
- MULTIPLE OPTIONAL SENSORS AVAILABLE
- POWER FACTOR:
- 0.9
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_FIXTURE
- SDS SHEET LINK:
- #REF!
- TEMPERATURE (CCT):
- 4000K
- WEIGHT LB.:
- 7.72
- WIRE COLOR:
- WHITE / BLACK / GREEN / GRAY / YELLOW
- WIRE QUANTITY:
- 5
- WIRE TEMP RATING:
- 105C (221F)
- QUANTITY AVAILABLE AT MANUFACTURER:
- 84
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 1.88
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 12.00
- FEATURE 1:
- LENGTH: 26.00 INCHES WIDTH: 12.00 INCHES HEIGHT: 1.88 INCHES''
- FEATURE 2:
- DAMP LOCATION RATED FOR INDOOR USE
- FEATURE 3:
- WHITE FINISH
- FEATURE 4:
- INTEGRATED SENSOR PORT
- FEATURE 5:
- 4000K COOL WHITE LIGHT
- FEATURE 6:
- RATED FOR 50000 HOURS
- FEATURE 7:
- DIMMABLE
- FEATURE 8:
- 5 YEAR LIMITED WARRANTY
- FEATURE 9:
- 15871 LUMENS
- LONG DESCRIPTION:
- SATCO
- QUANTITY IN PACK:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- NUMBER OF LAMPS:
- 1
- LAMPS:
- YES
- BULB KELVIN:
- COOL WHITE
- ANSI BASE:
- INTEGRATED
- BEAM SPREAD:
- 100
- CA PROP-65:
- LEAD
- CEC WEB TEXT:
- LAWFUL FOR SALE
- INCANDESCENT EQUIVALENT:
- 200W
- OPERATING TEMPRATURE:
- -40C (-40F) TO +50C (+122F)
- REPLACEABLE LIGHT SOURCE:
- NO
- REPLACES:
- #REF!
- SAFETY LISTING:
- CULUS - LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- IMAGE INFO:
- ''''
- WATTAGE SELECTABLE:
- NO
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- COOL WHITE
- EACH HEIGHT:
- 4.72''
- EACH LENGTH:
- 30.12
- EACH WIDTH:
- 15.16''
- TARIFF CODE:
- 9405.11.6020
- WIRE LENGTH:
- 5.91
- BAA COMPLIANT:
- NO
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EACH CUBE:
- 1.2472
- EACH QUANTITY:
- 1
- EFFICACY:
- 144.28 LPW
- JA8 COMPLIANT:
- NO
- ROMANCE COPY:
- SATCO
- SHORT DESCRIPTION:
- 110W LED ADJUSTABLE HIGH BAY
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- 15%
