12 Watt LED Direct Wire Downlight; 6-Inch; CCT Selectable; Round; Remote Driver; Black Finish {ADDITIONAL FINISH INFORMATION: ''Black''}
- AVAILABLE FOR PURCHASE:
- NO
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- STYLE:
- UTILITY
- BULB HOURS:
- 50000
- BULB KELVIN:
- WARM WHITE TO NATURAL LIGHT
- BULB SHAPE:
- INTEGRATED LED
- BULB TYPE:
- LED
- DIAMETER:
- 6.75
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.11.6010
- LUMENS:
- 1050L
- SHIP CARTON HEIGHT:
- 6.97''
- SHIP CARTON LENGTH:
- 6.89
- SHIP CARTON WIDTH:
- 2.17''
- WARRANTY:
- 5-YEARS
- AIR TIGHT:
- YES
- AMPS:
- 0.120A
- ANSI BASE:
- INTEGRATED
- BAA COMPLIANT:
- NO
- BEAM SPREAD:
- 110
- CA PROP-65:
- LEAD
- CARTON CUBIC FEET:
- 0.0603
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- CALIFORNIA T24 2016 - 2025 JA8 LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- CLOSET RATED:
- YES
- CONNECTION:
- HARDWIRE
- CRI:
- 90+
- DIMMABLE DOWN TO:
- 100 TO 10 PERCENT
- DIMMABLE FUNCTION:
- 120V ONLY
- DIMMING TYPE:
- LINE VOLTAGE
- EFFICACY:
- 87.50 LPW
- ES UNIQUE ID:
- 4480264
- FCC COMPLIANT:
- YES
- FEATURE 10:
- AIRTIGHT RATED
- FEATURE 2:
- 6-INCH ROUND
- FEATURE 3:
- 1050 LUMENS
- FEATURE 4:
- 12W LED IS A PERFECT REPLACEMENT FOR 75W INCANDESCENT APPLICATIONS
- FEATURE 5:
- CCT SELECTABLE 2700K/3000K/3500K/4000K/5000K
- FEATURE 6:
- 90 CRI
- FEATURE 7:
- 110-DEGREE BEAM ANGLE
- FEATURE 8:
- WET LOCATION RATED
- FEATURE 9:
- IC RATED
- FIXTURE SHAPE:
- ROUND
- HAS CAMERA:
- NO
- HAS DRIVER:
- YES
- HAS EMERGENCY BATTERY:
- NO
- IC RATED:
- YES
- INCANDESCENT EQUIVALENT:
- 75W
- IOT ENABLED:
- NO
- LENS MATERIAL:
- POLY METHYL METHACRYLATE (PMMA)
- LONG DESCRIPTION:
- SATCO NUVO'S S11875R1 PLUS SERIES LED SLIM FIT DOWNLIGHTS OFFER EXCEPTIONAL PERFORMANCE AND A SLEEK BLACK 6-INCH ROUND TRIM. COLORQUICK TECHNOLOGY ALLOWS FOR THE SELECTION FROM FIVE CCT CHOICES AT INSTALLATION TO CREATE THE PERFECT ATMOSPH...
- MATERIAL:
- ALUMINUM
- MOUNTING HEIGHT:
- 1.34''
- MOUNTING LENGTH:
- 6.18
- NSF APPROVED:
- NO
- OPERATING FREQUENCY:
- 60HZ
- OPERATING TEMPRATURE:
- -20C (-4F) TO +45C (+113F)
- ORDER IN MULTIPLES OF:
- 1
- PACK TYPE:
- COLOR BOX
- POWER FACTOR:
- >0.9
- QUANTITY IN PACK:
- 1
- REPLACEABLE LIGHT SOURCE:
- NO
- ROHS COMPLIANT:
- YES
- SAFETY LISTING:
- CETLUS - LISTED
- SDS CLASS:
- LED_FIXTURE
- SHORT DESCRIPTION:
- 12WLED/DW/6/CCT-SEL/RND/RD/BK
- SLOPED CEILING COMPATIBLE:
- YES
- TEMPERATURE (CCT):
- 2700K/3000K/3500K/4000K/5000K
- TITLE 20 COMPLIANT:
- EXEMPT
- TITLE 24 COMPLIANT:
- YES
- TOTAL HARMONIC DISTORTION:
- <20%
- TRIM COLOR:
- BLACK
- TRIM MATERIAL:
- ALUMINUM
- UP DOWN INSTALLATION:
- DOWN
- WATTAGE SELECTABLE:
- NO
- WEIGHT LB.:
- 1.12
- CEILING:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 2242
- IMAGE INFO:
- ''S11875R1.JPG:DEFAULT''
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 0.99
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 6.75
- WIDTH RANGE:
- 0-15''
- INDOOR OUTDOOR:
- INDOOR AND OUTDOOR
- JA8 COMPLIANT:
- YES
- SPECIFICATION NOTES:
- SUITABLE FOR USE IN CLOTHES CLOSETS WHEN INSTALLED IN ACCORDANCE WITH THE NEC 410.16 SPACING REQUIREMENTS
