12 Watt; LED; White; Barrel; Monopoint; 3000K; 36 deg. Beam Angle {ADDITIONAL FINISH INFORMATION: ''White''}
- STYLE:
- MODERN AND CONTEMPORARY
- BULB DIMMABLE:
- Yes - Dimmable
- BULB HOURS:
- 30000
- BULB TYPE:
- LED
- HARMONIZED CODES:
- 9405.11.8020
- LENGTH:
- 3
- LUMENS:
- 1020L
- SHIP CARTON HEIGHT:
- 4.75''
- SHIP CARTON LENGTH:
- 5
- SHIP CARTON WIDTH:
- 5''
- SHIP WEIGHT:
- 1.19
- WARRANTY:
- 3 Year Limited - Fixtures
- BEAM ANGLE:
- 36
- CARTON CUBIC FEET:
- 0.0687
- CARTONS PER UNIT:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- COLOR TEMPRATURE:
- Warm White
- CRI:
- 90
- LOCATION RATING:
- Dry
- OPERATING TEMP:
- -17C (+1.4F) TO +45C (+113F)
- HEIGHT:
- 2.25
- WIDTH:
- 4.75
- FINISH:
- WHITE
- LOCAL_ON_DISPLAY:
- 1
- ON DISPLAY IN SHOWROOM:
- Yes
- IN STOCK IN SHOWROOM:
- No
- STANDARD STYLE:
- MODERN
- DIMMABLE:
- Yes-Dimmable
- HEIGHT RANGE:
- 0-15''
- WIDTH RANGE:
- 0-15''
- BULB SHAPE:
- INTEGRATED LED
- AVAILABLE FOR PURCHASE:
- YES
- DIMMABLE FUNCTION:
- DIMMING RANGE FROM 100 TO LESS THAN OR EQUAL TO 20 PERCENT DEPENDING ON DIMMER CONTROL
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- QUANTITY AVAILABLE AT MANUFACTURER:
- 16
- ANSI BASE:
- INTEGRATED
- CONNECTION:
- HARDWIRE
- DIMMING TYPE:
- FORWARD PHASE OR REVERSE PHASE OR PHASE SELECTABLE
- FCC COMPLIANT:
- YES
- FEATURE 1:
- NEW MONO POINTS
- FEATURE 2:
- NEW LINEAR TRACK BARS
- FEATURE 3:
- EXPANDED TRACK HEAD OFFERING
- FEATURE 4:
- CUSTOMIZABLE ACCENT LIGHTING FOR LOW TO MID CEILING
- FEATURE 5:
- RESIDENTIAL AND COMMERCIAL
- FINISH FAMILY:
- WHITE
- INDOOR OUTDOOR:
- INDOOR
- LENS MATERIAL:
- POLY METHYL METHACRYLATE (PMMA)
- LONG DESCRIPTION:
- SATCO'S 62-1106 IS A 12-WATT LED MONOPOINT SPOTLIGHT WHICH IS HARDWIRED DIRECTLY TO THE CEILING OR WALL. THE FIXTURE HAS A BARREL SHAPE AND WHITE FINISH WHICH BLENDS WITH MANY DECOR STYLES. ITS INTEGRATED LED HAS A WARM WHITE COLOR TEMPERA...
- MATERIAL:
- ALUMINUM
- MOUNTING PROCEDURE:
- CEILING
- NUMBER OF LAMPS:
- 1
- OPERATING FREQUENCY:
- 60HZ
- PACK TYPE:
- BOX
- POWER FACTOR:
- >0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_FIXTURE
- TEMPERATURE (CCT):
- 3000K
- TRACK HEAD STYLE:
- BARREL
- WEIGHT LB.:
- 1.08
- LAMPS:
- YES
- AMPS:
- 0.100A
- SDS SHEET LINK:
- #REF!
- MOUNTING DIAMETER:
- 4.75
- MOUNTING HEIGHT:
- 0.5''
- BULB KELVIN:
- WARM WHITE
- BEAM SPREAD:
- 36
- CA PROP-65:
- LEAD
- CEC WEB TEXT:
- LAWFUL FOR SALE
- INCANDESCENT EQUIVALENT:
- 60W
- OPERATING TEMPRATURE:
- -17C (+1.4F) TO +45C (+113F)
- REPLACEABLE LIGHT SOURCE:
- NO
- SAFETY LISTING:
- CETLUS - LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CCT SELECTABLE:
- NO
- WATTAGE SELECTABLE:
- NO
- REPLACES:
- #REF!
- AVG RATED HOURS:
- 30000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM WHITE
- EACH HEIGHT:
- 4.75''
- EACH LENGTH:
- 5
- EACH WIDTH:
- 5''
- TARIFF CODE:
- 9405.11.8020
- BAA COMPLIANT:
- NO
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EACH CUBE:
- 0.0687
- EACH QUANTITY:
- 1
- EFFICACY:
- 85.00 LPW
- JA8 COMPLIANT:
- NO
- ROMANCE COPY:
- THIS SATCO TRACK EXPANSION INCLUDES MONO POINTS LINEAR TRACK BARS AND THE ADDITION OF SEVERAL NEW TRACK HEADS WITH MODERN PROFILES AND ADJUSTABLE DESIGN FEATURES OFFERING EVEN MORE VERSATILITY AND NEW DIRECTION TO OUR TRACK PRODUCTS! THE...
- SHORT DESCRIPTION:
- 12W LED BARREL MONOPOINT
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
