2 Light; LED Large Up and Down Sconce Fixture; White Finish; 20W; 120/277V {ADDITIONAL FINISH INFORMATION: ''White''}
- STYLE:
- Utility
- BULB DIMMABLE:
- Non-Dimmable
- BULB HOURS:
- 50000
- BULB SHAPE:
- Integrated LED
- BULB TYPE:
- LED
- DIAMETER:
- 3.35
- EXTENDS:
- 4.21
- HARMONIZED CODES:
- 9405.11.6020
- LUMENS:
- 1800L
- SHIP CARTON HEIGHT:
- 12.8''
- SHIP CARTON LENGTH:
- 5.91
- SHIP CARTON WIDTH:
- 5.71''
- SHIP WEIGHT:
- 3.17
- VOLTAGE:
- 277V
- WARRANTY:
- 5 Year Limited - Fixtures
- BEAM ANGLE:
- 40
- CARTON CUBIC FEET:
- 0.25
- CARTONS PER UNIT:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- COLOR TEMPRATURE:
- Warm White
- CRI:
- 90
- IP RATING:
- IP65
- LOCATION RATING:
- Wet
- MOUNTING:
- Wall
- OPERATING TEMP:
- -30C (-22F) TO +50C (+122F)
- PACK TYPE:
- Box
- PHOTOCELL:
- No Photocell
- HEIGHT:
- 11.69
- WIDTH:
- 4.53
- FINISH:
- WHITE
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- No
- BULBS:
- 10W WATT:10W WATT:2
- Standard Style:
- Traditional
- DIMMABLE:
- Non-Dimmable
- WIDTH RANGE:
- 0-15''
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 2 INTEGRATED BULBS
- QUANTITY AVAILABLE AT MANUFACTURER:
- 49
- ANSI BASE:
- INTEGRATED
- CONNECTION:
- DIRECT WIRED
- ES UNIQUE ID:
- ESID-2336402
- FCC COMPLIANT:
- YES
- FEATURE 1:
- CREATE AN ARCHITECTURAL DETAIL WITH LIGHT - EXTEND SPACE DRAWING THE EYE VERTICALLY ELONGATING AND CREATING DIMENSION AND INTRIGUE
- FEATURE 2:
- FIXTURE DIMENSIONAL SPECIFICATIONS (IN INCHES) HEIGHT: 11.75 DIAMETER: 3.16 WIDTH: 5.00 EXT: 4.22''
- FEATURE 3:
- DIRECT WIRED INSTALLATION WET RATED FOR OUTDOOR USE
- FEATURE 4:
- INTEGRATED LED
- FEATURE 5:
- 90 CRI SUPERIOR QUALITY LED LIGHT RATED FOR 50000 HOURS FOR AN ENERGY EFFICIENT LIGHTING OPTION
- FEATURE 6:
- ARCHITECTURAL OUTDOOR DESIGN
- FEATURE 7:
- 5 YEAR LIMITED WARRANTY. SEE MANUFACTURER WEBSITE FOR DETAILS
- FINISH FAMILY:
- WHITE
- INDOOR OUTDOOR:
- OUTDOOR
- INSTALLATION NOTES:
- MOUNTS UP AND DOWN
- LONG DESCRIPTION:
- SATCO'S 62-1143R1 2 LIGHT 12 INCH WHITE UP AND DOWN SCONCE IS MODERN SLEEK AND CONTEMPORARY IN DESIGN. CASTING ELONGATED COLUMNS OF LIGHT FROM BOTH THE TOP AND BOTTOM INSTALL THIS WHITE FIXTURE TO ELONGATE AND BRING PRESENCE TO A STRUC...
- MATERIAL:
- DIE-CAST ALUMINUM
- MOUNTING HEIGHT:
- 4.53''
- MOUNTING PROCEDURE:
- WALL
- MOUNTING WIDTH:
- 4.53''
- NUMBER OF LAMPS:
- 2
- POWER FACTOR:
- 0.99
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_FIXTURE
- TEMPERATURE (CCT):
- 3000K
- UP DOWN INSTALLATION:
- UNIVERSAL
- WEIGHT LB.:
- 2.51
- LAMPS:
- YES
- AMPS:
- 0.167/0.072A
- SDS SHEET LINK:
- #REF!
- BULB KELVIN:
- WARM WHITE
- BEAM SPREAD:
- 40
- CA PROP-65:
- LEAD
- CEC WEB TEXT:
- LAWFUL FOR SALE
- OPERATING TEMPRATURE:
- -30C (-22F) TO +50C (+122F)
- REPLACEABLE LIGHT SOURCE:
- NO
- REPLACES:
- #REF!
- SAFETY LISTING:
- CULUS - LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CCT SELECTABLE:
- NO
- WATTAGE SELECTABLE:
- NO
- INCANDESCENT EQUIVALENT:
- 100W
- OPERATING FREQUENCY:
- 50/60HZ
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM WHITE
- EACH HEIGHT:
- 12.8''
- EACH LENGTH:
- 5.91
- EACH WIDTH:
- 5.71''
- TARIFF CODE:
- 9405.11.6020
- BAA COMPLIANT:
- NO
- EACH CUBE:
- 0.25
- EACH QUANTITY:
- 1
- EFFICACY:
- 90.00 LPW
- JA8 COMPLIANT:
- NO
- MOUNTING EXTENDS:
- 0.63
- R9 VALUE:
- 63
- ROMANCE COPY:
- SATCO'S 2 LIGHT 12 INCH WHITE UP AND DOWN SCONCE IS MODERN SLEEK AND CONTEMPORARY IN DESIGN. CASTING ELONGATED COLUMNS OF LIGHT FROM BOTH THE TOP AND BOTTOM INSTALL THIS WHITE FIXTURE TO ELONGATE AND BRING PRESENCE TO A STRUCTURE. ELEG...
- SHORT DESCRIPTION:
- 2 LT LED LG UP & DOWN SCONCE
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
