20W LED Bulk Head Fixture; White Finish {ADDITIONAL FINISH INFORMATION: ''White''}
- STYLE:
- Bulk Head
- BULB DIMMABLE:
- Non-Dimmable
- BULB HOURS:
- 50000
- BULB SHAPE:
- Integrated LED
- BULB TYPE:
- LED
- EXTENDS:
- 5.5
- HARMONIZED CODES:
- 9405.11.6010
- LUMENS:
- 1440L
- SHIP CARTON HEIGHT:
- 6.02''
- SHIP CARTON LENGTH:
- 12.95
- SHIP CARTON WIDTH:
- 8.78''
- SHIP WEIGHT:
- 5.6
- VOLTAGE:
- 120V
- WARRANTY:
- 5 Year Limited - Fixtures
- CARTON CUBIC FEET:
- 0.3961
- CARTONS PER UNIT:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- COLOR TEMPRATURE:
- Warm White
- CRI:
- 90
- LOCATION RATING:
- Wet
- PACK TYPE:
- Box
- HEIGHT:
- 11.25
- WIDTH:
- 7.00
- FINISH:
- WHITE
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- No
- BULBS:
- 20W WATT INTEGRATED LED:20W WATT INTEGRATED LED:1
- STANDARD STYLE:
- TRADITIONAL
- DIMMABLE:
- Non-Dimmable
- WIDTH RANGE:
- 0-15''
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- QUANTITY AVAILABLE AT MANUFACTURER:
- 86
- ANSI BASE:
- INTEGRATED
- CONNECTION:
- DIRECT WIRED
- ES UNIQUE ID:
- ESID-2298580
- FCC COMPLIANT:
- YES
- FEATURE 1:
- WIDTH: 7.00 INCHES HEIGHT: 11.25 INCHES EXTENDS: 5.50 INCHES''
- FEATURE 2:
- SUPERIOR 90 CRI LIGHT QUALITY
- FEATURE 3:
- WHITE FINISH
- FEATURE 4:
- DIRECT WIRED CONNECTION
- FEATURE 5:
- 1440 LUMENS
- FEATURE 6:
- WET LOCATION RATED FOR OUTDOOR USE
- FEATURE 7:
- EASY INSTALLATION
- FEATURE 8:
- FCC AND ROHS COMPLIANT
- FEATURE 9:
- 5 YEAR LIMITED WARRANTY
- FINISH FAMILY:
- WHITE
- INDOOR OUTDOOR:
- OUTDOOR
- LONG DESCRIPTION:
- SATCO'S 65-113 20 WATT LED BULK HEAD IS AN ATTRACTIVE HIGH EFFICIENCY WALL FIXTURE GOOD FOR BOTH INDOOR AND OUTDOOR APPLICATIONS. ILLUMINATE DOCKS WALKWAYS ENTRANCES PATIOS AND POOL DECKS WITH THIS DURABLE DIE-CAST ALUMINUM BULK HEAD...
- MOUNTING PROCEDURE:
- WALL
- NUMBER OF LAMPS:
- 1
- POWER FACTOR:
- 0.99
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_FIXTURE
- TEMPERATURE (CCT):
- 3000K
- WEIGHT LB.:
- 5.32
- LAMPS:
- YES
- AMPS:
- 0.200-0.072A
- SDS SHEET LINK:
- #REF!
- BULB KELVIN:
- WARM WHITE
- CA PROP-65:
- LEAD
- CEC WEB TEXT:
- LAWFUL FOR SALE
- REPLACEABLE LIGHT SOURCE:
- NO
- SAFETY LISTING:
- CETLUS - LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CCT SELECTABLE:
- NO
- MATERIAL:
- DIE-CAST ALUMINUM
- WATTAGE SELECTABLE:
- NO
- INCANDESCENT EQUIVALENT:
- 100W
- REPLACES:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM WHITE
- EACH HEIGHT:
- 6.02''
- EACH LENGTH:
- 12.95
- EACH WIDTH:
- 8.779999999999999''
- TARIFF CODE:
- 9405.11.6010
- BAA COMPLIANT:
- NO
- EACH CUBE:
- 0.3961
- EACH QUANTITY:
- 1
- EFFICACY:
- 72.00 LPW
- JA8 COMPLIANT:
- NO
- ROMANCE COPY:
- SATCO'S 20 WATT LED BULK HEAD IS AN ATTRACTIVE HIGH EFFICIENCY WALL FIXTURE GOOD FOR BOTH INDOOR AND OUTDOOR APPLICATIONS. ILLUMINATE DOCKS WALKWAYS ENTRANCES PATIOS AND POOL DECKS WITH THIS DURABLE DIE-CAST ALUMINUM BULK HEAD. THIS ...
- SHORT DESCRIPTION:
- 20W LED BULK HEAD
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- <20%
- LENS MATERIAL:
- GLASS
- OPERATING TEMP:
- -20C (-4F) TO +40C (+104F)
