23 Watt PLL LED ballast bypass; 2G11 base; 2800 Lumens; 120-277 Volt; 3500K; Type B; Ballast Bypass {ADDITIONAL FINISH INFORMATION: ''White''}
- BULB DIMMABLE:
- Non-Dimmable
- BULB HOURS:
- 50000
- BULB KELVIN:
- 3500K
- BULB SHAPE:
- T5
- DIAMETER:
- 0.63
- HARMONIZED CODES:
- 8539.52.0091
- LENGTH:
- 22.5
- LUMENS:
- 2800L
- SHIP CARTON HEIGHT:
- 1.1''
- SHIP CARTON LENGTH:
- 23
- SHIP CARTON WIDTH:
- 1.8''
- SHIP WEIGHT:
- 0.45
- VOLTS:
- 120V-277V
- WARRANTY:
- 5 Year Limited - 10 hr per day
- BEAM SPREAD:
- 270
- BULB ANSI BASE:
- 2G11
- BULB BASE:
- 2G11
- BULB FINISH:
- Frost
- BURNING POSITION:
- Universal
- CARTON CUBIC FEET:
- 0.0264
- CARTONS PER UNIT:
- 1
- CEC:
- Exempt - Base Not Regulated
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- Neutral White
- CRI:
- 82
- DLC APPROVED:
- YES
- DLC ID:
- P0O7T912
- ENCLOSURE RATING:
- ENCLOSED RATED LAMP
- FLUORESCENT EQUIVALENT:
- 40W
- HOUSING COLOR:
- White
- LAMP FILAMENT:
- LED
- LENS:
- YES
- LOCATION RATING:
- Damp
- NSF APPROVED:
- Yes
- OPERATING TEMP:
- -20C (-4F) TO +45C (+113F)
- PACK TYPE:
- Box
- WATTS:
- 23W
- WIDTH:
- 0.63
- WIDTH RANGE:
- 0-15''
- LAMPS:
- YES
- FINISH:
- WHITE
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- No
- Standard Style:
- Traditional
- DIMMABLE:
- Non-Dimmable
- AVAILABLE FOR PURCHASE:
- NO
- QUANTITY AVAILABLE AT MANUFACTURER:
- 10729
- WEIGHT:
- 0.39
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- DLC CLASSIFICATION:
- STANDARD
- DLC PRIMARY USE:
- INTERNAL DRIVER/LINE VOLTAGE (UL TYPE B) LAMPS
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LENS FINISH:
- FROST
- OPERATING FREQUENCY:
- 50/60HZ
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- RATED FOR VAPOR TIGHT FIXTURE:
- NO
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- SDS SHEET LINK:
- SDS/LED_LAMP.PDF
- TECHNOLOGY:
- LED
- CCT SELECTABLE:
- NO
- MATERIAL:
- ALUMINUM / PLASTIC
- WATTAGE SELECTABLE:
- NO
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 100W
- EFFICACY:
- 121.74 LPW
- ENCLOSED FIXTURE USE:
- YES
- R9 VALUE:
- 9
- SHORT DESCRIPTION:
- 23PLL/LED/835/BP
- TITLE 20 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- 20%
- EA LENGTH:
- 23
- SHAP CARTON WIDTH:
- 1.8''
- FLOURESCENT EQUIVALENT:
- 40W
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- TITLE 24 COMPLIANT:
- NO
- JA8 COMPLIANT:
- NO
