2X2 Single Basket LED Troffer Fixture; Wattage Selectable; CCT Selectable; Lumens Selectable; 100-277V {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- STYLE:
- UTILITY
- BULB HOURS:
- 50000
- BULB SHAPE:
- INTEGRATED LED
- BULB TYPE:
- LED
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.11.6020
- LENGTH:
- 23.74
- LUMENS:
- 3300L-4400L
- SHIP CARTON HEIGHT:
- 25.67''
- SHIP CARTON LENGTH:
- 3.75
- SHIP CARTON WIDTH:
- 25.63''
- SHIP WEIGHT:
- 7.94
- WARRANTY:
- 5 YEAR LIMITED - FIXTURES
- CARTON CUBIC FEET:
- 1.4278
- CARTONS PER UNIT:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- COLOR TEMPRATURE:
- WARM TO COOL WHITE
- CRI:
- 80
- DIMMABLE FUNCTION:
- 0-10V DIMMING ONLY
- DLC APPROVED:
- YES
- DLC ID:
- PLHP5OXLTQ43
- IP RATING:
- IP20
- LOCATION RATING:
- DAMP
- OPERATING TEMP:
- -20C (-4F) TO +40C (+104F)
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 2KV
- FINISH:
- WHITE
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 2.61
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 23.74
- WIDTH RANGE:
- 20-25''
- STANDARD STYLE:
- TRADITIONAL
- QUANTITY AVAILABLE AT MANUFACTURER:
- UNKNOWN
- IMAGE INFO:
- ''''
- ANSI BASE:
- INTEGRATED
- CCT SELECTABLE:
- YES
- DIMMING TYPE:
- 0-10V
- DLC CLASSIFICATION:
- STANDARD
- DLC PRIMARY USE:
- 2X2 LUMINAIRES FOR AMBIENT LIGHTING OF INTERIOR COMMERCIAL SPACES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- VOLUMETRIC DESIGN
- FEATURE 2:
- WATTS: 30W - 35W - 40W
- FEATURE 3:
- LUMENS: 3300L - 4400L
- FEATURE 4:
- COLOR TEMPERATURE: 3500K/4000K/5000K
- FEATURE 5:
- OPERATING TEMPERATURE: -20C (-4F) TO A MAXIMUM OF 40C (104F)
- FEATURE 6:
- DLC PREMIUM CERTIFIED
- FINISH FAMILY:
- WHITE
- FIXTURE SHAPE:
- SQUARE
- FLICKER FREE:
- YES
- HAS DRIVER:
- YES
- HID EQUIV:
- 70W-100W
- IC RATED:
- YES
- INDOOR OUTDOOR:
- INDOOR
- LENS MATERIAL:
- POLY METHYL METHACRYLATE (PMMA)
- LONG DESCRIPTION:
- SATCO
- MATERIAL:
- STEEL
- MOUNTING PROCEDURE:
- CEILING
- NUMBER OF LAMPS:
- 1
- PACK TYPE:
- BOX
- PANEL SIZE:
- 2X2
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_FIXTURE
- TEMPERATURE (CCT):
- 3500K/4000K/5000K
- WATTAGE SELECTABLE:
- YES
- WEIGHT LB.:
- 6.06
- LAMPS:
- YES
- AMPS:
- 0.300-0.108/0.350-0.126/0.400-0.144A
- SDS SHEET LINK:
- #REF!
- BULB KELVIN:
- WARM TO COOL WHITE
- CA PROP-65:
- LEAD
- OPERATING TEMPRATURE:
- -20C (-4F) TO +40C (+104F)
- REPLACEABLE LIGHT SOURCE:
- NO
- SAFETY LISTING:
- CULUS - CERTIFIED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CONNECTION:
- HARDWIRE
- CEC WEB TEXT:
- LAWFUL FOR SALE
- BEAM SPREAD:
- 120
- OPERATING FREQUENCY:
- 50/60HZ
- POWER FACTOR:
- 0.9
- INCANDESCENT EQUIVALENT:
- 125W
- REPLACES:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM TO COOL WHITE
- EACH HEIGHT:
- 25.67''
- EACH LENGTH:
- 3.75
- EACH WIDTH:
- 25.63''
- TARIFF CODE:
- 9405.11.6020
- BAA COMPLIANT:
- NO
- BEAM ANGLE:
- 120
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EACH CUBE:
- 1.4278
- EACH QUANTITY:
- 1
- EFFICACY:
- 110.00/110.00/110.00 LPW
- JA8 COMPLIANT:
- NO
- ROMANCE COPY:
- A TWO FOOT BY TWO FOOT SINGLE BASKET TROFFER WHICH FEATURE SELECTABLE WATTAGE AND COLOR TEMPERATURE. THE TROFFER FEATURES AN ACRYLIC LINEAR PRISMATIC LENS WHICH ALLOWS FOR BROAD EVEN LIGHT DISTRIBUTION. THE DRIVER ALLOWS FOR FLICKER-FREE ...
- SHORT DESCRIPTION:
- 2X2 SINGLE BASKET TROFFER
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- <20%
