32 Watt T8 LED; CCT Selectable; 120-277 Volt; Single or Double Ended; Type B Ballast Bypass {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 50000
- BULB KELVIN:
- 4000K/5000K/6500K
- BULB SHAPE:
- T8
- DIAMETER:
- 1.13
- DIMMABLE:
- NON-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0051
- LENGTH:
- 81.81
- LUMENS:
- 4500L/4650L/4400L
- SHIP CARTON HEIGHT:
- 1.15''
- SHIP CARTON LENGTH:
- 84
- SHIP CARTON WIDTH:
- 1.15''
- SHIP WEIGHT:
- 1.37
- VOLTS:
- 120V-277V
- WARRANTY:
- 5-YEARS
- WEIGHT:
- 1.35
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- BEAM SPREAD:
- 360
- BULB ANSI BASE:
- R17D
- BULB BASE:
- RECESSED DOUBLE CONTACT HO/VHO
- BURNING POSITION:
- UNIVERSAL
- CARTON CUBIC FEET:
- 0.0643
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- EXEMPT - BASE NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- COOL WHITE TO DAYLIGHT
- CRI:
- 80+
- ENCLOSURE RATING:
- YES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- 4000K/5000K/6500K CCT SELECTABLE
- FEATURE 2:
- DOUBLE SIDED LED FOR 360 DEGREES OF ILLUMINATION
- FEATURE 3:
- UL TYPE B - BALLAST BYPASS INSTALLATION
- FEATURE 4:
- RATED FOR 50000 HOURS
- FEATURE 5:
- 120-277 VOLTS
- FEATURE 6:
- DAMP LOCATION RATED
- FEATURE 7:
- FCC AND ROHS COMPLIANT
- FLUORESCENT EQUIVALENT:
- 100W
- INDOOR OUTDOOR:
- INDOOR
- IP RATING:
- IP20
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LAMP FILAMENT:
- LED
- LENS MATERIAL:
- PLASTIC
- LOCATION RATING:
- DAMP
- LONG DESCRIPTION:
- SATCO NUVO'S S16439 32-WATT T8 LAMP IS THE PERFECT LIGHTING SOLUTION FOR BALANCING ENERGY EFFICIENCY ADVANCED TECHNOLOGY AND STYLE. THIS DOUBLE SIDED LED LAMP DELIVERS 360 DEGREES OF ILLUMINATION IN 4000K 5000K OR 6500K CCT. COLOR TEM...
- MATERIAL:
- POLYCARBONATE (PC)
- NOMINAL LENGTH:
- 84.0
- NSF APPROVED:
- ETL SANITATION LISTED (CONFORMS TO NSF)
- OPERATING FREQUENCY:
- 50/60HZ
- OPERATING TEMP:
- -20C (-4F) TO +45C (+113F)
- PACK TYPE:
- EGG CRATE
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- TECHNOLOGY:
- LED
- TUBE GUARD USE:
- NO
- WATTS:
- 32W
- LAMPS:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 2514
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 1.13
- WIDTH RANGE:
- 0-15''
- More Info {1}:
- 120-277 VOLTS
- More Info {2}:
- 4000K/5000K/6500K CCT SELECTABLE
- More Info {3}:
- DAMP LOCATION RATED
- More Info {4}:
- DOUBLE SIDED LED FOR 360 DEGREES OF ILLUMINATION
- More Info {5}:
- FCC AND ROHS COMPLIANT
- More Info {6}:
- RATED FOR 50000 HOURS
- More Info {7}:
- UL TYPE B - BALLAST BYPASS INSTALLATION
- DLC APPROVED:
- NO
- ORDER IN MULTIPLES OF:
- 10
- SDS CLASS:
- LED_LAMP
- WATTAGE SELECTABLE:
- NO
- IMAGE INFO:
- ''S16439.JPG:DEFAULT''
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 125W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- EFFICACY:
- 140.63/145.31/137.50 LPW
- ENCLOSED FIXTURE USE:
- YES
- JA8 COMPLIANT:
- NO
- LAMP END TYPE:
- SINGLE ENDED DOUBLE ENDED
- R9 VALUE:
- 17
- ROMANCE COPY:
- SATCO NUVO'S LED T8 SIGN LAMPS ARE THE IDEAL LAMP TO REPLACE TRADITIONAL T8 LAMPS. WITH FOURTEEN SIZES FROM 18 INCHES TO 120 INCHES THESE LAMPS CAN FIT VIRTUALLY ANY SIZE SIGN CABINET. EASILY INSTALL THE LAMPS WITH DIRECT SINGLE OR DOUBLE...
- SHORT DESCRIPTION:
- 32T8/LED/HO-SIGN/84-3CCT/BP/SE
- TITLE 20 COMPLIANT:
- EXEMPT
- TOTAL HARMONIC DISTORTION:
- 25%
- CA PROP-65:
- LEAD
- BULB DIMMABLE:
- NON-DIMMABLE
- EA LENGTH:
- 84.0
- SHAP CARTON WIDTH:
- 1.15''
- FLOURESCENT EQUIVALENT:
- 100W
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 1KV
- TITLE 24 COMPLIANT:
- NO
- DLC CLASSIFICATION:
- CCT SELECTABLE
- START TYPE:
- UTILITY
- STYLE:
- UTILITY
- HOUSING COLOR:
- WHITE
- CATEGORY:
- LED
- SUB-CATEGORY:
- LED T8
- COUNTRY OF ORIGIN:
- CHINA
- 4/29/2025 14:
- 19
- FINISH:
- LAMPS
- STANDARD STYLE:
- LED LAMPS
- HAS CAMERA:
- NO
- HAS EMERGENCY BATTERY:
- NO
- IOT ENABLED:
- NO
