40 Watt; 8 Foot; T8 LED; Single pin base; 3500K; 50000 Average rated hours; 5300 Lumens; Type B; Ballast Bypass; Double Ended Wiring; DLC 5.1 {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 50000
- BULB KELVIN:
- 3500K
- BULB SHAPE:
- T8
- DIAMETER:
- 1.0
- DIMMABLE:
- NON-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0051
- LENGTH:
- 93.88
- LUMENS:
- 5300L
- SHIP CARTON HEIGHT:
- 1.0''
- SHIP CARTON LENGTH:
- 94
- SHIP CARTON WIDTH:
- 1''
- SHIP WEIGHT:
- 0.9
- VOLTS:
- 120V-277V
- WARRANTY:
- 5-YEARS
- WEIGHT:
- 0.88
- BEAM SPREAD:
- 210
- BULB ANSI BASE:
- FA8
- BULB BASE:
- SINGLE PIN
- BULB FINISH:
- WHITE
- CARTON CUBIC FEET:
- 0.0544
- CARTONS PER UNIT:
- 1
- CEC:
- EXEMPT - BASE NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- NEUTRAL WHITE
- CRI:
- 80+
- DLC APPROVED:
- YES
- DLC ID:
- PLSDLWQ3P1GE
- ENCLOSURE RATING:
- ENCLOSED RATED LAMP
- FLUORESCENT EQUIVALENT:
- 59W
- LAMP FILAMENT:
- LED
- LOCATION RATING:
- DAMP
- NOMINAL LENGTH:
- 96.0
- NSF APPROVED:
- YES
- OPERATING TEMP:
- -20C (-4F) TO +45C (+113F)
- PACK TYPE:
- SLEEVE
- SHATTER PROOF TEXT:
- PET COATED
- WATTS:
- 40W
- LAMPS:
- YES
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 1.00
- WIDTH RANGE:
- 0-15''
- QUANTITY AVAILABLE AT MANUFACTURER:
- 954
- IMAGE INFO:
- ''S29917.JPG:DEFAULT''
- ADDITIONAL INFO:
- SUITABLE FOR EMERGENCY LIGHTING ONLY WITH SATCO EM DRIVER #S8002
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- BURNING POSITION:
- UNIVERSAL
- CCT SELECTABLE:
- NO
- DLC CLASSIFICATION:
- STANDARD
- DLC PRIMARY USE:
- INTERNAL DRIVER/LINE VOLTAGE (UL TYPE B) LAMPS
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- MOL: 94 INCHES MOD: 1 INCH
- FEATURE 2:
- SUPERIOR 82 CRI LIGHT QUALITY 5300 LUMENS AND 3500K WITH A 210 BEAM SPREAD
- FEATURE 3:
- RATED FOR ENCLOSED FIXTURES
- FEATURE 4:
- DAMP RATED FOR INDOOR USE ONLY
- FEATURE 5:
- 40 WATT LED REPLACES 59 WATT FLUORESCENT
- FEATURE 6:
- WHITE FINISHED LINEAR GLASS LAMP
- FEATURE 7:
- DLC CERTIFIED AND QUALIFIES FOR REBATES WHERE AVAILABLE
- FEATURE 8:
- 5 YEAR LIMITED WARRANTY
- INDOOR OUTDOOR:
- INDOOR
- IOT ENABLED:
- NO
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LENS FINISH:
- WHITE
- LONG DESCRIPTION:
- SATCO NUVO'S S29917 40 WATT T8 LED 8 FOOT LINEAR TYPE B BALLAST BYPASS COMMERCIAL LINEAR REPLACEMENT LAMP OFFERS LONG LED LIFE PACKS 5300 POWERFUL LUMENS OF BRIGHT AND IS DLC CERTIFIED ENERGY EFFICIENT. DOUBLE ENDED WIRING FOR CONVENIENC...
- MATERIAL:
- GLASS
- MINIMUM COMPARTMENT SIZE:
- LENGTH: 96.063 IN. WIDTH: 10.630 IN. HEIGTH: 2.756 IN.''
- OPERATING FREQUENCY:
- 50/60HZ
- ORDER IN MULTIPLES OF:
- 10
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- TECHNOLOGY:
- LED
- FINISH:
- WHITE
- STANDARD STYLE:
- TRADITIONAL
- More Info {1}:
- SUITABLE FOR EMERGENCY LIGHTING ONLY WITH SATCO EM DRIVER #S8002
- More Info {2}:
- 5 YEAR LIMITED WARRANTY
- More Info {3}:
- DAMP RATED FOR USE INDOOR USE ONLY
- More Info {4}:
- DLC CERTIFIED AND QUALIFIES FOR REBATES WHERE AVAILABLE
- More Info {5}:
- MOL: 94 INCHES MOD: 1 INCH
- More Info {6}:
- RATED FOR ENCLOSED FIXTURES
- More Info {7}:
- SUPERIOR 82 CRI LIGHT QUALITY 5300 LUMENS AND 3500K WITH A 210 BEAM SPREAD
- WATTAGE SELECTABLE:
- NO
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 125W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- EFFICACY:
- 132.50 LPW
- ENCLOSED FIXTURE USE:
- YES
- LAMP END TYPE:
- DOUBLE ENDED
- R9 VALUE:
- 12
- ROMANCE COPY:
- SATCO NUVO'S 40 WATT T8 LED 8 FOOT LINEAR TYPE B BALLAST BYPASS COMMERCIAL LINEAR REPLACEMENT LAMP OFFERS LONG LED LIFE PACKS 5300 POWERFUL LUMENS OF BRIGHT AND IS DLC CERTIFIED ENERGY EFFICIENT. DOUBLE ENDED WIRING FOR CONVENIENCE THE ...
- SHORT DESCRIPTION:
- 40T8/LED/96-835/BP/FA8
- TITLE 20 COMPLIANT:
- EXEMPT
- TOTAL HARMONIC DISTORTION:
- 20%
- CA PROP-65:
- LEAD
- EA LENGTH:
- 94.0
- SHAP CARTON WIDTH:
- 1.0''
- FLOURESCENT EQUIVALENT:
- 59W
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- TITLE 24 COMPLIANT:
- NO
- JA8 COMPLIANT:
- NO
- BULB DIMMABLE:
- SLEEVE
- LENS MATERIAL:
- LED
- START TYPE:
- UTILITY
- STYLE:
- UTILITY
- HOUSING COLOR:
- WHITE
- CATEGORY:
- LED
- SUB-CATEGORY:
- LED T8
- COUNTRY OF ORIGIN:
- CHINA
- 4/30/2025 14:
- 17
- HAS CAMERA:
- NO
- HAS EMERGENCY BATTERY:
- NO
