5.5 Watt PAR20 LED; Medium Base; Silver Finish; CCT Selectable; 120 Volt; 25 Degree Beam Angle {ADDITIONAL FINISH INFORMATION: ''Silver''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 25000
- BULB KELVIN:
- 2700K/3000K/3500K/4000K/5000K
- BULB SHAPE:
- PAR20
- DIAMETER:
- 2.48
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0030
- LENGTH:
- 3.19
- LUMENS:
- 500L
- SHIP CARTON HEIGHT:
- 3.5''
- SHIP CARTON LENGTH:
- 2.64
- SHIP CARTON WIDTH:
- 2.64''
- SHIP WEIGHT:
- 0.05
- VOLTS:
- 120V
- WARRANTY:
- 5-YEARS
- WEIGHT:
- 0.1
- BEAM SPREAD:
- 25
- BULB ANSI BASE:
- E26
- BULB BASE:
- MEDIUM
- BURNING POSITION:
- UNIVERSAL
- CARTON CUBIC FEET:
- 0.0141
- CARTONS PER UNIT:
- 1
- CBCP:
- 1255
- CCT SELECTABLE:
- YES
- CEC:
- CALIFORNIA T24 2016 - 2025 JA8 LISTED T20 LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- WARM WHITE TO NATURAL LIGHT
- CRI:
- 90+
- DIMMING TYPE:
- FORWARD PHASE OR REVERSE PHASE OR PHASE SELECTABLE
- ENCLOSURE RATING:
- YES
- FCC COMPLIANT:
- YES
- FLUORESCENT EQUIVALENT:
- 11W
- HOUSING COLOR:
- SILVER
- INCANDESCENT EQUIVALENT:
- 50W
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- LAMP FILAMENT:
- LED
- LENS:
- YES
- LENS MATERIAL:
- POLYCARBONATE (PC)
- LOCATION RATING:
- WET
- MATERIAL:
- POLYAMIDE (PA)
- OPERATING FREQUENCY:
- 60HZ
- OPERATING TEMP:
- -20C (-4F) TO +40C (+104F)
- PACK TYPE:
- BOX
- POWER FACTOR:
- 0.7
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- SPOT TYPE:
- SP - SPOT
- TECHNOLOGY:
- LED
- WATTAGE SELECTABLE:
- NO
- WATTS:
- 5.5W
- LAMPS:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 0
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 2.48
- WIDTH RANGE:
- 0-15''
- FEATURE 1:
- 5 CCT SELECTABLE WITH UNIQUE COLOR SELECTION DIAL
- FEATURE 2:
- WET LOCATION RATED
- FEATURE 3:
- INDOOR OR OUTDOOR USE
- FEATURE 4:
- RATED FOR USE IN ENCLOSED FIXTURES
- FEATURE 5:
- 90 CRI
- FEATURE 6:
- 5.5W
- FEATURE 7:
- DIMMABLE
- LONG DESCRIPTION:
- SATCO NUVO'S LED S11580 PAR LAMP IS THE PERFECT SOLUTION FOR RECESSED AND FLOOD LIGHTING. THE PAR20 25 DEGREE BEAM ANGLE OFFERS THE BEST ILLUMINATION FOR YOUR APPLICATION. FEATURES A UNIQUE DIAL FOR THE CHOICE BETWEEN 2700K/3000K/3500K/400...
- IMAGE INFO:
- ''S11580.JPG:DEFAULT''
- BAA COMPLIANT:
- NO
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EFFICACY:
- 90.91 LPW
- ENCLOSED FIXTURE USE:
- YES
- JA8 COMPLIANT:
- YES
- R9 VALUE:
- 40
- ROMANCE COPY:
- SATCO NUVO'S LED PAR LAMPS ARE THE PERFECT SOLUTION FOR RECESSED AND FLOOD LIGHTING. OFFERED IN PAR20 PAR30 PAR30 LONG NECK AND PAR38 CHOOSE 25 40 OR 60 DEGREE BEAM ANGLES FOR THE BEST ILLUMINATION FOR YOUR APPLICATION. ALL MODELS INCL...
- SHORT DESCRIPTION:
- 5.5PAR20/LED/5CCT/SP/120V
- STYLE:
- UTILITY
- TITLE 20 COMPLIANT:
- YES
- CA PROP-65:
- LEAD
- BULB DIMMABLE:
- YES-DIMMABLE
- EA LENGTH:
- 2.64
- SHAP CARTON WIDTH:
- 2.64''
- FLOURESCENT EQUIVALENT:
- 11W
- DLC APPROVED:
- NO
- TITLE 24 COMPLIANT:
- YES
- DLC CLASSIFICATION:
- CCT SELECTABLE
- SENSOR TYPE:
- NON FEDERALLY-REGULATED
- START TYPE:
- UTILITY
- ORDER IN MULTIPLES OF:
- 1
- CATEGORY:
- LED
- SUB-CATEGORY:
- LED PAR
- COUNTRY OF ORIGIN:
- CHINA
- 4/29/2025 14:
- 19
- FINISH:
- LIGHT BULBS
- STANDARD STYLE:
- LED BULBS
- 5/2/2025 21:
- 28
- 5/5/2025 14:
- 15
- 5/6/2025 14:
- 19
- HAS CAMERA:
- NO
- HAS EMERGENCY BATTERY:
- NO
- IOT ENABLED:
- NO
