20/40/60 Wattage Selectable; LED Hi-Pro Wall Pack; CCT Selectable 3K/4K/5K; Type B; Ballast Bypass; Extended Mogul base; 100-277 Volt; ColorQuick Technology; PowerQuick Technology {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 50000
- BULB KELVIN:
- 3000K/4000K/5000K
- BULB SHAPE:
- CORNCOB
- DIAMETER:
- 3.62
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0091
- LENGTH:
- 10.6
- LUMENS:
- 3200L/6500L/9000L
- SHIP CARTON HEIGHT:
- 11.88''
- SHIP CARTON LENGTH:
- 4
- SHIP CARTON WIDTH:
- 4''
- SHIP WEIGHT:
- 2.55
- VOLTS:
- 120V-277V
- WARRANTY:
- 5-YEARS
- WEIGHT:
- 2.24
- BEAM SPREAD:
- 180
- BULB ANSI BASE:
- EX39
- BULB BASE:
- MOGUL EXTENDED
- BULB FINISH:
- WHITE
- BURNING POSITION:
- HORIZONTAL
- CARTON CUBIC FEET:
- 0.11
- CARTONS PER UNIT:
- 1
- CEC:
- EXEMPT - BASE NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- CRI:
- 80+
- DIMMABLE FUNCTION:
- DIMMABLE ONLY VIA THE WATTAGE/LUMEN SELECTABLE DIAL INCLUDED ON LAMP
- ENCLOSURE RATING:
- ENCLOSED RATED LAMP
- HID EQUIVALENT:
- 250W
- HOUSING COLOR:
- WHITE
- IP RATING:
- IP64
- LAMP FILAMENT:
- LED
- LOCATION RATING:
- DAMP
- NSF APPROVED:
- NO
- OPERATING TEMP:
- -30C (-22F) TO +45C (+113F)
- PACK TYPE:
- BOX
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 4KV
- WATTS:
- 20W/40W/60W
- LAMPS:
- YES
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 3.62
- WIDTH RANGE:
- 0-15''
- DLC APPROVED:
- YES
- DLC ID:
- PWQMWM48
- QUANTITY AVAILABLE AT MANUFACTURER:
- 272
- COLOR TEMPRATURE:
- WARM TO COOL WHITE
- IMAGE INFO:
- ''S28987.JPG:DEFAULT''
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- CCT SELECTABLE:
- YES
- DLC CLASSIFICATION:
- STANDARD
- DLC PRIMARY USE:
- REPLACEMENT LAMPS FOR OUTDOOR POLE/ARM-MOUNTED AREA AND ROADWAY LUMINAIRES (TYPE B)
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- CCT SELECTABLE-3000K 4000K 5000K
- FEATURE 2:
- WATTAGE SELECTABLE
- FEATURE 3:
- ADVANCED THERMAL MANAGEMENT
- FEATURE 4:
- 4KV BUILT-IN SURGE PROTECTION
- FEATURE 5:
- RATED FOR USE IN ENCLOSED FIXTURES
- FEATURE 6:
- DAMP LOCATION RATED
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- IOT ENABLED:
- NO
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LENS MATERIAL:
- PLASTIC
- LONG DESCRIPTION:
- SATCO NUVO'S S28987 WATTAGE AND CCT SELECTABLE HI-PRO LED LAMP IS AN ENERGY EFFICIENT LIGHTING SOLUTION FOR LARGE SCALE LIGHTING APPLICATIONS. DESIGNED TO FOCUS CLEAN AND EFFICIENT LED LIGHT AT 180 DEGREES FROM HIGHER FIXTURES THIS LAMP I...
- MATERIAL:
- ALUMINUM / PLASTIC
- MINIMUM COMPARTMENT SIZE:
- LENGTH: 8 IN. WIDTH: 8 IN. HEIGHT: 12 IN.''
- OPERATING FREQUENCY:
- 50/60HZ
- POWER FACTOR:
- >0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- TECHNOLOGY:
- LED
- WATTAGE SELECTABLE:
- YES
- STANDARD STYLE:
- TRADITIONAL
- More Info {1}:
- 4KV BUILT-IN SURGE PROTECTION
- More Info {2}:
- ADVANCED THERMAL MANAGEMENT
- More Info {3}:
- CCT SELECTABLE-3000K 4000K 5000K
- More Info {4}:
- DAMP LOCATION RATED
- More Info {5}:
- RATED FOR USE IN ENCLOSED FIXTURES
- More Info {6}:
- WATTAGE SELECTABLE
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 100W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- B.U. G. RATING:
- B3-U3-G3
- EFFICACY:
- 160.00/162.50/150.00 LPW
- ENCLOSED FIXTURE USE:
- YES
- R9 VALUE:
- 8
- ROMANCE COPY:
- SATCO NUVO'S WATTAGE AND CCT SELECTABLE HI-PRO LED LAMP IS AN ENERGY EFFICIENT LIGHTING SOLUTION FOR LARGE SCALE LIGHTING APPLICATIONS. DESIGNED TO FOCUS CLEAN AND EFFICIENT LED LIGHT AT 180 DEGREES FROM HIGHER FIXTURES THIS LAMP IS PERFE...
- SHORT DESCRIPTION:
- 60W/LED/WP/CCT/EX39/100-277V
- STYLE:
- CONTEMPORARY
- TITLE 20 COMPLIANT:
- EXEMPT
- CA PROP-65:
- LEAD
- EA LENGTH:
- 4.0
- SHAP CARTON WIDTH:
- 4.0''
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- TITLE 24 COMPLIANT:
- NO
- JA8 COMPLIANT:
- NO
- BULB DIMMABLE:
- BOX
- START TYPE:
- CONTEMPORARY
- FINISH:
- LIGHT BULBS
- CATEGORY:
- LED
- SUB-CATEGORY:
- HID REPLACEMENTS
- COUNTRY OF ORIGIN:
- CHINA
- 4/30/2025 14:
- 19
- HAS CAMERA:
- NO
- HAS EMERGENCY BATTERY:
- NO
