9.5 Watt; 4 Foot; T8 LED; Medium bi-pin base; 5000K; 50000 Average rated hours; 1740 Lumens; Type A; Ballast dependent {ADDITIONAL FINISH INFORMATION: ''Gloss''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 50000
- BULB KELVIN:
- 5000K
- BULB SHAPE:
- T8
- DIAMETER:
- 1
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0051
- LENGTH:
- 48
- LUMENS:
- 1740L
- SHIP CARTON HEIGHT:
- 1.1''
- SHIP CARTON LENGTH:
- 48
- SHIP CARTON WIDTH:
- 1.1''
- SHIP WEIGHT:
- 0.51
- VOLTS:
- BALLAST DEPENDENT
- WARRANTY:
- 5-YEARS
- WEIGHT:
- 0.42
- BEAM SPREAD:
- 210
- BULB ANSI BASE:
- G13
- BULB BASE:
- MEDIUM BI PIN
- BULB FINISH:
- GLOSS
- CARTON CUBIC FEET:
- 0.0336
- CARTONS PER UNIT:
- 1
- CEC:
- EXEMPT - BASE NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- NATURAL LIGHT
- CRI:
- 80+
- DIMMABLE FUNCTION:
- ONLY IN TYPE A MODE CHECK BALLAST MFG FOR DIMMER COMPATIBILITY
- DLC APPROVED:
- YES
- DLC ID:
- PL2JWH754LKM
- FLUORESCENT EQUIVALENT:
- 32W/30W/28W/25W
- HOUSING COLOR:
- WHITE
- LAMP FILAMENT:
- LED
- LOCATION RATING:
- DAMP
- NOMINAL LENGTH:
- 48
- NSF APPROVED:
- YES
- OPERATING TEMP:
- -20C (-4F) TO +45C (+113F)
- PACK TYPE:
- SLEEVE
- WATTS:
- 9.5W
- LAMPS:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 25
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 1.00
- WIDTH RANGE:
- 0-15''
- IMAGE INFO:
- ''S11743.JPG:DEFAULT''
- BALLAST BYPASS DIRECT:
- DIRECT
- BALLASTING REQUIREMENTS:
- BALLAST REQUIRED. DIRECT REPLACEMENT-FOR USE ON INSTANT START AND RAPID START BALLASTS WITH NO REWIRING REQUIRED. MAY NOT BE COMPATIBLE WITH EVERY BALLAST. REFER TO THE BALLAST COMPATIBILITY CHART
- CCT SELECTABLE:
- NO
- DLC CLASSIFICATION:
- STANDARD
- DLC PRIMARY USE:
- REPLACEMENT LAMPS (PLUG AND PLAY) (UL TYPE A)
- FCC COMPLIANT:
- YES
- FEATURE 1:
- UP TO 183 LUMENS PER WATT (LPW)
- FEATURE 2:
- ALL GLASS TUBES - NO AGING YELLOWING OR BENDING
- FEATURE 3:
- COMPATIBLE WITH MOST INSTANT START RAPID START T8 ELECTRONIC BALLASTS
- FEATURE 4:
- DAMP LOCATION RATED
- FEATURE 5:
- DLC 5.1 CERTIFIED
- FEATURE 6:
- INTEGRATED THERMAL FUSE AT PINS
- FEATURE 7:
- OPERATING TEMPERATURE: -20C (-4F) TO A MAXIMUM OF 45C (113F)
- FEATURE 8:
- LONG LIFE - RATED FOR 50000 HOURS
- INDOOR OUTDOOR:
- INDOOR
- IOT ENABLED:
- NO
- LAMP BALLAST TYPE A/B/C:
- TYPE A
- LONG DESCRIPTION:
- SATCO NUVO'S S11743 9.5-WATT 5000K T8 FLUORESCENT REPLACEMENT LAMP ALLOWS THE FIXTURE TO MAINTAIN ITS ORIGINAL UL AND CSA COMPLIANCE WHILE DELIVERING EFFICIENT LED LIGHTING. THIS LAMP PROVIDES 50000 HOURS OF NATURAL LIGHT. COMMERCIAL HE...
- MATERIAL:
- GLASS
- OPERATING FREQUENCY:
- 50/60HZ
- ORDER IN MULTIPLES OF:
- 25
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- SPECIFICATION NOTES:
- SURGE PROTECTION
- TECHNOLOGY:
- LED
- STANDARD STYLE:
- TRADITIONAL
- BURNING POSITION:
- UNIVERSAL
- More Info {1}:
- ALL GLASS TUBES - NO AGING YELLOWING OR BENDING
- More Info {2}:
- COMPATIBLE WITH MOST INSTANT START RAPID START T8 ELECTRONIC BALLASTS
- More Info {3}:
- DAMP LOCATION RATED
- More Info {4}:
- DLC 5.1 CERTIFIED
- More Info {5}:
- INTEGRATED THERMAL FUSE AT PINS
- More Info {6}:
- LONG LIFE - RATED FOR 50000 HOURS
- More Info {7}:
- OPERATING TEMPERATURE: -20C (-4F) TO A MAXIMUM OF 45C (113F)
- More Info {8}:
- UP TO 183 LUMENS PER WATT (LPW)
- WATTAGE SELECTABLE:
- NO
- ENCLOSURE RATING:
- 0
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 75W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EFFICACY:
- 183.16 LPW
- R9 VALUE:
- 12
- ROMANCE COPY:
- SATCO NUVO'S 9.5-WATT 5000K T8 FLUORESCENT REPLACEMENT LAMP ALLOWS THE FIXTURE TO MAINTAIN ITS ORIGINAL UL AND CSA COMPLIANCE WHILE DELIVERING EFFICIENT LED LIGHTING. THIS LAMP PROVIDES 50000 HOURS OF NATURAL LIGHT. COMMERCIAL HEALTH CA...
- SHORT DESCRIPTION:
- 9.5/T8/LED/48-850/DR
- TITLE 20 COMPLIANT:
- EXEMPT
- TOTAL HARMONIC DISTORTION:
- 20%
- CA PROP-65:
- LEAD
- BULB DIMMABLE:
- YES-DIMMABLE
- EA LENGTH:
- 48
- SHAP CARTON WIDTH:
- 1.1''
- FLOURESCENT EQUIVALENT:
- 32W/30W/28W/25W
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- LENS MATERIAL:
- LED
- START TYPE:
- UTILITY
- STYLE:
- UTILITY
- TITLE 24 COMPLIANT:
- NO
- JA8 COMPLIANT:
- NO
- FINISH:
- LIGHT BULBS
- CATEGORY:
- LED
- SUB-CATEGORY:
- LED T8
- COUNTRY OF ORIGIN:
- CHINA
