90 Watt LED HID Replacement; 5000K; Mogul Extended base; Adjustable Beam Angle; Type B Ballast Bypass;100-277 Volt {ADDITIONAL FINISH INFORMATION: ''No Finish''}
- BULB DIMMABLE:
- NON-DIMMABLE
- BULB HOURS:
- 50000
- BULB KELVIN:
- 5000K
- BULB SHAPE:
- Corncob
- DIAMETER:
- 4.84
- HARMONIZED CODES:
- 8539.52.0091
- LENGTH:
- 9.84
- LUMENS:
- 12600L
- SHIP CARTON HEIGHT:
- 11.61''
- SHIP CARTON LENGTH:
- 5.51
- SHIP CARTON WIDTH:
- 5.51''
- SHIP WEIGHT:
- 4.47
- VOLTS:
- 100V-277V
- WARRANTY:
- 5 YEAR LIMITED - HI-PRO
- WEIGHT:
- 3.48
- BEAM SPREAD:
- 120/150/260
- BULB ANSI BASE:
- EX39
- BULB BASE:
- Mogul Extended
- BULB FINISH:
- Clear
- CARTON CUBIC FEET:
- 0.204
- CARTONS PER UNIT:
- 1
- CEC:
- Exempt - Base Not Regulated
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- NATURAL LIGHT
- CRI:
- 80
- DLC APPROVED:
- NO
- DLC ID:
- NO
- ENCLOSURE RATING:
- ENCLOSED RATED LAMP
- FLUORESCENT EQUIVALENT:
- 150W
- HID EQUIVALENT:
- 600W
- HOUSING COLOR:
- White
- INCANDESCENT EQUIVALENT:
- 750W
- IP RATING:
- IP64
- LAMP FILAMENT:
- LED
- LENS:
- YES
- LOCATION RATING:
- DAMP
- OPERATING TEMP:
- -20C (-4F) TO +65C (+149F)
- PACK TYPE:
- BOX
- PHOTOCELL:
- Optional Add-On
- SURGE PROTECTION:
- Built-in surge protection - 4KV
- WATTS:
- 90W
- WIDTH:
- 4.84
- WIDTH RANGE:
- 0-15''
- LAMPS:
- YES
- FINISH:
- WHITE
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- No
- Standard Style:
- Traditional
- DIMMABLE:
- Non-Dimmable
- AVAILABLE FOR PURCHASE:
- NO
- BURNING POSITION:
- BASE UP OR DOWN
- QUANTITY AVAILABLE AT MANUFACTURER:
- UNKNOWN
- ADDITIONAL INFO:
- PIR SENSOR AVAILABLE AS AN ACCESSORY
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- CCT SELECTABLE:
- NO
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- GREATER EFFICIENCY
- FEATURE 2:
- IMPROVED HEAT DISSIPATION
- FEATURE 3:
- BUILT-IN 4KV SURGE PROTECTION
- FEATURE 4:
- MULTIPLE BEAM ANGLE OPTIONS
- FEATURE 5:
- PORT FOR MOTION SENSOR
- FEATURE 6:
- L:9.84 D:4.84
- HAS DRIVER:
- YES
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- IOT ENABLED:
- NO
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LENS FINISH:
- CLEAR
- LENS MATERIAL:
- THERMO PLASTIC (PBT)
- LONG DESCRIPTION:
- SATCO'S S39679 90-WATT HID REPLACEMENT LED LAMP OFFERS NATURAL LIGHT AND AN ADJUSTABLE BEAM SPREAD. SUITABLE FOR OUTDOOR POLE LAMPS THIS HIGH LUMEN LAMP WITH A MOGUL EXTENDED BASE PROVIDES SUPERIOR ILLUMINATION. THIS ENERGY EFFICIENT LED...
- MATERIAL:
- ALUMINUM / STEEL / THERMO PLASTIC (PBT)
- MINIMUM COMPARTMENT SIZE:
- WIDTH: 17.30 IN. DEPTH: 17.30 IN. HEIGHT: 11.90 IN.''
- OPERATING FREQUENCY:
- 50/60HZ
- POWER FACTOR:
- >0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- SDS SHEET LINK:
- #REF!
- SPECIFICATION NOTES:
- CLOSED 260 DEG PARTIAL 150 DEG OPEN 120 DEG
- TECHNOLOGY:
- LED
- ORDER IN MULTIPLES OF:
- 1
- More Info {1}:
- PIR SENSOR AVAILABLE AS AN ACCESSORY
- More Info {2}:
- GREATER EFFICIENCY
- More Info {3}:
- IMPROVED HEAT DISSIPATION
- More Info {4}:
- L:9.84 D:4.84
- More Info {5}:
- MULTIPLE BEAM ANGLE OPTIONS
- More Info {6}:
- PORT FOR MOTION SENSOR
- WATTAGE SELECTABLE:
- NO
- BAA COMPLIANT:
- NO
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- EFFICACY:
- 140.00 LPW
- ENCLOSED FIXTURE USE:
- YES
- R9 VALUE:
- 11
- ROMANCE COPY:
- THE THIRD GENERATION OF MULTIBEAM LAMPS OFFER IMPROVED EFFICIENCY PERFORMANCE AND INSTALLATION VERSATILITY. WITH AN IMPRESSIVE 140 LUMENS PER WATT A REDESIGNED AND MORE EFFICIENT HEAT SINK AND AN OPTIONAL PIR MOTION SENSOR THE MULTIBE...
- SHORT DESCRIPTION:
- 90W/LED/HID/MB-G3/50K/100-277V
- STYLE:
- UTILITY
- TITLE 20 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- <20%
- CA PROP-65:
- LEAD
- IMAGE INFO:
- ''''
- EA LENGTH:
- 5.51
- SHAP CARTON WIDTH:
- 5.51''
- FLOURESCENT EQUIVALENT:
- 150W
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- TITLE 24 COMPLIANT:
- NO
- JA8 COMPLIANT:
- NO
- DLC CLASSIFICATION:
- MULTI-BEAM
- START TYPE:
- UTILITY
