LED Horizontal Step Light; 5W; Gray Finish; 120V {ADDITIONAL FINISH INFORMATION: ''Gray''}
- STYLE:
- Utility
- BULB DIMMABLE:
- Yes - Dimmable
- BULB HOURS:
- 50000
- BULB SHAPE:
- Integrated LED
- BULB TYPE:
- LED
- HARMONIZED CODES:
- 9405.42.6000
- LENGTH:
- 1.63
- LUMENS:
- 407L
- SHIP CARTON HEIGHT:
- 2.2''
- SHIP CARTON LENGTH:
- 5.2
- SHIP CARTON WIDTH:
- 3.2''
- SHIP WEIGHT:
- 0.45
- VOLTAGE:
- 120V
- WARRANTY:
- 5 Year Limited - Fixtures
- CARTON CUBIC FEET:
- 0.0212
- CARTONS PER UNIT:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- COLOR TEMPRATURE:
- Warm White
- CRI:
- 80
- LOCATION RATING:
- Wet
- MOUNTING:
- Strip
- PACK TYPE:
- Box
- HEIGHT:
- 3.00
- WIDTH:
- 5.00
- FINISH:
- GRAY
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- No
- BULBS:
- 5W WATT:5W WATT:1
- STANDARD STYLE:
- TRADITIONAL
- DIMMABLE:
- Yes-Dimmable
- HEIGHT RANGE:
- 0-15''
- WIDTH RANGE:
- 0-15''
- AVAILABLE FOR PURCHASE:
- NO
- DIMMABLE FUNCTION:
- DIMMING RANGE FROM 100 TO LESS THAN OR EQUAL TO 20 PERCENT DEPENDING ON DIMMER CONTROL
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- QUANTITY AVAILABLE AT MANUFACTURER:
- 6
- ANSI BASE:
- INTEGRATED
- CONNECTION:
- DIRECT WIRED
- DIMMING TYPE:
- FORWARD PHASE OR REVERSE PHASE
- FCC COMPLIANT:
- YES
- FEATURE 1:
- LENGTH: 1.63 INCHES WIDTH: 3.00 INCHES HEIGHT: 5.00 INCHES''
- FEATURE 2:
- DIMMABLE
- FEATURE 3:
- GRAY FINISH
- FEATURE 4:
- 3000K WARM WHITE LIGHT
- FEATURE 5:
- 407 LUMENS
- FEATURE 6:
- WET LOCATION RATED
- FEATURE 7:
- EASY INSTALLATION
- FEATURE 8:
- FCC AND ROHS COMPLIANT
- FEATURE 9:
- 5 YEAR LIMITED WARRANTY
- FINISH FAMILY:
- GRAY
- INSTALLATION NOTES:
- NOT CONCRETE RATED REQUIRES A RECESSED SWITCH BOX WITH A MINIMUM INTERIOR BOX VOLUME OF 13 CUBIC INCHES.
- LENS MATERIAL:
- GLASS
- LONG DESCRIPTION:
- SATCO'S 65-411 5 WATT HORIZONTAL STEP LIGHT IS AN EASY TO INSTALL FIXTURE DESIGNED TO LIGHT THE WAY. THE RUGGED CONSTRUCTION OF THIS GRAY FIXTURE ENSURES THAT IT IS DURABLE ENOUGH TO WITHSTAND HARSH WEATHER CONDITIONS. DIMMABLE AND SPACE S...
- MATERIAL:
- DIE-CAST ALUMINUM
- MOUNTING PROCEDURE:
- HORIZONTAL STEP STRIP
- NUMBER OF LAMPS:
- 1
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_FIXTURE
- TEMPERATURE (CCT):
- 3000K
- WEIGHT LB.:
- 0.43
- LAMPS:
- YES
- AMPS:
- 0.042A
- SDS SHEET LINK:
- #REF!
- BULB KELVIN:
- WARM WHITE
- CA PROP-65:
- LEAD
- CEC WEB TEXT:
- LAWFUL FOR SALE
- REPLACEABLE LIGHT SOURCE:
- NO
- SAFETY LISTING:
- CULUS
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CCT SELECTABLE:
- NO
- WATTAGE SELECTABLE:
- NO
- INCANDESCENT EQUIVALENT:
- 20W
- OPERATING FREQUENCY:
- 50/60HZ
- REPLACES:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM WHITE
- EACH HEIGHT:
- 2.2''
- EACH LENGTH:
- 5.2
- EACH WIDTH:
- 3.2''
- TARIFF CODE:
- 9405.42.6000
- BAA COMPLIANT:
- NO
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EACH CUBE:
- 0.0212
- EACH QUANTITY:
- 1
- EFFICACY:
- 81.40 LPW
- JA8 COMPLIANT:
- NO
- ROMANCE COPY:
- SATCO'S 5 WATT HORIZONTAL STEP LIGHT IS AN EASY TO INSTALL FIXTURE DESIGNED TO LIGHT THE WAY. THE RUGGED CONSTRUCTION OF THIS GRAY FIXTURE ENSURES THAT IT IS DURABLE ENOUGH TO WITHSTAND HARSH WEATHER CONDITIONS. DIMMABLE AND SPACE SAVING ...
- SHORT DESCRIPTION:
- LED 5W HORIZONTAL STEP LIGHT
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
- INDOOR OUTDOOR:
- OUTDOOR
