Designed by Chicago architect Stephen Katz, the Nan ceiling fan is a contemporary take on traditional fan design with superior performance and functionality. The Nan fan feels at home in any room or setting from casual to formal and everything in between. This timeless ceiling fan works in residential environments, restaurants, hospitality or even office settings. The Nan fan has the perfect amount of design presence for any size room or season. The fully adjustable fan motor speeds makes moving the right amount of air simple and easy. The Nan fan will feel like a natural part of the room and enhance any space with a fresh breeze. Also available is the larger Nan XL for larger spaces. {ADDITIONAL FINISH INFORMATION: ''Matte White''}
- AVAILABLE FOR PURCHASE:
- NO
- SIZE:
- 425260
- STYLE:
- CONTEMPORARY TRANSITIONAL
- FAMILY NAME:
- NAN
- AIR FLOW CFM:
- 5281
- AIR FLOW EFFICIENCY:
- 175
- BLADE PITCH:
- 15
- BLADES INCLUDED:
- 3
- DEPTH:
- 42
- DOWN ROD INCLUDED:
- 10
- ELECTRICITY USED:
- 28.43
- MAX HEIGHT:
- 84''
- MOTOR FAN SPEED:
- 6-SPEED
- MOTOR RPM:
- 266
- MOTOR TYPE:
- DC
- SHIP CARTON HEIGHT:
- 11''
- SHIP CARTON LENGTH:
- 24
- SHIP CARTON WIDTH:
- 12''
- SOLD IN PACK OF:
- 2
- WARRANTY:
- LIMITED LIFETIME
- WEIGHT:
- 18
- 12:
- SILENT OPERATION FOR COOLING WITHOUT NOISE
- APPLICATION:
- INDOOR OUTDOOR DAMP KITCHEN LIVINGROOM PATIO LANAI PORCH DEN BEDROOM NOISE SENSITIVE ENVIRONMENTS GREAT ROOM OFFICE
- BLADE MATERIAL:
- SOLID WOOD
- BLADE SHIPPING DIMENSIONS-H:
- 8
- BLADE SHIPPING DIMENSIONS-L:
- 24
- BLADE SHIPPING DIMENSIONS-W:
- 6
- BLADE SHIPPING WEIGHT-LBS:
- 5
- BRAND:
- ATLAS
- CANCELLABILITY - STOCKING:
- YES
- FAN SHIPPING WEIGHT-LBS:
- 17
- FEATURE:
- CONSTRUCTED OF CAST ALUMINUM AND HEAVY STAMPED STEEL.
- FEATURE1:
- LIMITED LIFETIME WARRANTY
- FEATURE2:
- STANDARD EQUIPMENT: SLANT CEILING CANOPY MOUNTING SYSTEM FOR UP TO 29 DEGREES. OPTIONAL 60 DEGREE CATHEDRAL CANOPY MOUNTING SYSTEM AVAILABLE.
- FEATURE3:
- STANDARD EQUIPMENT: 10'' DOWNROD. THE FAN CAN BE MOUNTED WITH ANY OF THE FOLLOWING DOWNROD LENGTHS: 5'' 10'' 20'' 30'' 48'' AND 72'' HOWEVER.
- FEATURE4:
- STANDARD EQUIPMENT: HAND-HELD REMOTE AND DECORA-STYLE WALL-MOUNTED 6-SPEED WIRELESS CONTROLS.
- FEATURE5:
- THIS FAN CAN BE UPGRADED TO 72'' OR 90'' IN DIAMETER
- FEATURE6:
- THIS FAN IS PACKAGED WITH BOTH REMOTE AND WALL CONTROLS.
- HARMONIZED CODE:
- 8414.51.30
- INCLUDED CONTROL:
- REMOTE CONTROL WALL CONTROL
- IP RATING:
- IP20
- LEAD TIME:
- 3 DAYS
- LO CRM:
- 884
- LO RPM:
- 50
- LOCATION RATING:
- DAMP RATED
- PROP 20:
- YES
- ROD LENGTH:
- 5'' 10'' 20'' 30'' 48'' 72''
- SAFETY RATING:
- ETL APPROVED CETL APPROVED
- STANDARD CARRIERS:
- FEDEX OR UPS
- QUANTITY AVAILABLE AT MANUFACTURER:
- UNKNOWN
- IMAGE INFO:
- ''NK-MWH-LM-42-01.JPG:DEFAULT''
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 42.00
- WIDTH RANGE:
- 40-45''
- FAN OR PART:
- FAN
- FINISH:
- WHITE
- STANDARD STYLE:
- CONTEMPORARY
- OPTION:
- OUTDOOR
- OPTION1:
- TITLE 20
- AMPERAGE:
- 0.42
- BLADE SPAN:
- 42
- CANOPY:
- 6 W X 6 D X 2 H
- DESIGNER:
- STEPHEN KATZ
- INTRODUCTION DATE:
- 01/01/2022
- LIGHT KIT INCLUDED:
- NO
- MATERIAL:
- CAST ALUMINUM STAMPED STEEL SOLID WOOD
- ORDER MINIMUM:
- 1
- SHIP WEIGHT:
- 17
- VENDOR SHIP METHOD:
- SMALL PARCEL
- More Info {1}:
- 0.3 AMP
- More Info {2}:
- COMPATIBLE WITH SLANTED CEILINGS UP TO 30 DEGREES FOR FLEXIBLE INSTALLATION. OPTIONAL 60 DEGREES CATHEDRAL CANOPY MOUNTING SYSTEM AVAILABLE
- More Info {3}:
- CONSTRUCTED OF CAST ALUMINUM AND HEAVY STAMPED STEEL
- More Info {4}:
- ENERGY EFFICIENT ULTRA-QUIET 6-SPEED AND REVERSIBLE DC MOTOR WITH NEW RELIABLE TECHNOLOGY
- More Info {5}:
- ENHANCE COMFORT AND EFFICIENCY THROUGHOUT DIFFERENT SEASONS BY ADJUSTING THE DIRECTION OF AIRFLOW WITH THE REVERSE FUNCTION
- More Info {6}:
- HAND-HELD REMOTE AND DECORA-STYLE WALL-MOUNTED 6-SPEED WIRELESS CONTROLS
- More Info {7}:
- IDEAL FOR MEDIUM-SIZED BEDROOMS SMALL HOME OFFICES OR KITCHENS.
- More Info {8}:
- IP20
- More Info {9}:
- MADE WITH MOISTURE AND HUMIDITY-RESISTANT MATERIALS SUITABLE FOR COVERED OUTDOOR SPACES SUCH AS PATIOS PORCHES OR SUNROOMS
- 10:
- MEDIUM: ROOMS 76-144 SQ. FT. 36-42 INCH BLADE SPAN
- 11:
- OVERALL DROP: 12''
- 13:
- STANDARD EQUIPMENT: 10'' DOWNROD. ADDITIONAL DOWNROD LENGTHS ARE AVAILABLE AND SOLD SEPARATELY TO ACHIEVE THE OPTIMAL LOOK AND FUNCTIONALITY FOR YOUR SPACE
- ASSEMBLY REQUIRED:
- YES
- BLADE SIZE:
- 42
- BLADE WIDTH:
- 6''
- CARTON 2 HEIGHT:
- 8''
- CARTON 2 LENGTH:
- 24
- CARTON 2 WEIGHT:
- 5
- CARTON 2 WIDTH:
- 6''
- CFM AVERAGE:
- 3083
- CFM HIGH:
- 5281
- CFM LOW:
- 884
- COLOR:
- MATTE WHITE LIGHT MAPLETONE
- COMMERCIAL OR RESIDENTIAL USE:
- BOTH
- CONTROL FREQUENCY 110V:
- 304MHZ
- CONTROL FREQUENCY 220V:
- 434MHZ
- DOWNROD DIAMETER:
- 1
- FAN WATTAGE AT HIGH SPEED:
- 28.43
- HANGING TYPE:
- DOWNROD
- HEIGHT ADJUSTABLE:
- YES''
- INDOOR:
- YES
- MARINE RATED:
- NO
- MATERIAL PERCENTAGE:
- 25% CAST ALUMINUM 25% STAMPED STEEL 50% WOOD
- MIN HEIGHT:
- 17''
- MOTOR REVERSIBLE:
- YES
- NOISE LEVEL:
- SILENT
- NUMBER OF BLADES:
- 3
- NUMBER OF BOXES:
- 2
- NUMBER OF SPEEDS:
- 6
- OSCILLATES:
- NO
- OUTDOOR:
- YES
- PROP 65 DESCRIPTION:
- WARNING: THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS WHICH ARE KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. WWW.P65WARNINGS.CA.GOV.
- RETURNABLE:
- YES
- RPM HIGH:
- 267
- RPM LOW:
- 50
- SHIP CONTAINER:
- BOX
- SHIP LEAD TIME:
- 3 DAYS
- SLOPED CEILING COMPATIBLE:
- YES
- TITLE 20:
- YES
- WOOD TYPE:
- PAULOWNIA
- CEILING:
- YES
- HEIGHT:
- 12.00
