10 Watt T8 LED; CCT Selectable; G13 base; 50000 Average rated hours; Type A; Ballast Dependent; 25 PK {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 50000
- BULB KELVIN:
- 4000K/5000K/6500K
- BULB SHAPE:
- T8
- DIAMETER:
- 1
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0051
- LENGTH:
- 48
- LUMENS:
- 1800L
- SHIP CARTON HEIGHT:
- 6.7''
- SHIP CARTON LENGTH:
- 50
- SHIP CARTON WIDTH:
- 6.5''
- SHIP WEIGHT:
- 8.75
- VOLTS:
- BALLAST DEPENDENT
- WARRANTY:
- 5 YEAR LIMITED - T8 LED BULBS
- WEIGHT:
- 0.46
- BEAM SPREAD:
- 220
- BULB ANSI BASE:
- G13
- BULB BASE:
- MEDIUM BI PIN
- BULB FINISH:
- WHITE
- CARTON CUBIC FEET:
- 1.2601
- CARTONS PER UNIT:
- 1
- CEC:
- EXEMPT - BASE NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- CRI:
- 80+
- DIMMABLE FUNCTION:
- DIMMING RANGE FROM 100 TO LESS THAN OR EQUAL TO 20 PERCENT DEPENDING ON DIMMER CONTROL
- DLC APPROVED:
- YES
- DLC ID:
- PGH969QL
- ENCLOSURE RATING:
- YES
- FLUORESCENT EQUIVALENT:
- 30W
- HOUSING COLOR:
- WHITE
- IP RATING:
- IP20
- LAMP FILAMENT:
- LED
- LOCATION RATING:
- DAMP
- NSF APPROVED:
- YES
- OPERATING TEMP:
- -20C (-4F) TO +45C (+113F)
- WATTS:
- 10W
- LAMPS:
- YES
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 1.00
- WIDTH RANGE:
- 0-15''
- QUANTITY AVAILABLE AT MANUFACTURER:
- UNKNOWN
- IMAGE INFO:
- ''''
- BALLAST BYPASS DIRECT:
- DIRECT
- BALLASTING REQUIREMENTS:
- BALLAST REQUIRED CHECK COMPATIBILITY
- CCT SELECTABLE:
- YES
- COLOR TEMPRATURE:
- COOL WHITE TO DAYLIGHT
- DLC CLASSIFICATION:
- STANDARD
- DLC PRIMARY USE:
- REPLACEMENT LAMPS (PLUG AND PLAY) (UL TYPE A)
- FCC COMPLIANT:
- YES
- FEATURE 1:
- BALLAST BYPASS REPLACES A FOUR-FOOT T8 LAMP
- FEATURE 2:
- SINGLE SLEEVE PACK
- FEATURE 3:
- ALL-GLASS TUBE
- FEATURE 4:
- BALLAST-COMPATIBLE REPLACES A T8 LAMP ON ELECTRONIC IS AND RS BALLASTS
- FEATURE 5:
- FIVE-YEAR WARRANTY
- FEATURE 6:
- TYPE A LAMP BALLAST
- FEATURE 7:
- IP20 RATING
- HAS EMERGENCY BATTERY:
- NO
- INDOOR OUTDOOR:
- INDOOR
- IOT ENABLED:
- NO
- LAMP BALLAST TYPE A/B/C:
- TYPE A
- LENS FINISH:
- FROST
- LENS MATERIAL:
- GLASS
- MATERIAL:
- GLASS
- OPERATING FREQUENCY:
- 50/60HZ
- ORDER IN MULTIPLES OF:
- 25
- PACK TYPE:
- SLEEVE
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 25
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- TECHNOLOGY:
- LED
- TUBE GUARD USE:
- NO
- STANDARD STYLE:
- TRADITIONAL
- LONG DESCRIPTION:
- SATCO'S S11928 10-WATT LED T8 IS A VERSATILE CCT SELECTABLE LIGHTING SOLUTION PERFECT FOR A WIDE RANGE OF FIXTURES AND APPLICATIONS. THIS EASY TO INSTALL LOW MAINTENANCE LAMP GIVES YOU THE OPTION BETWEEN THREE COLOR TEMPERATURES: 4000K...
- BURNING POSITION:
- UNIVERSAL
- More Info {1}:
- ALL-GLASS TUBE
- More Info {2}:
- BALLAST BYPASS REPLACES A FOUR-FOOT T8 LAMP
- More Info {3}:
- BALLAST-COMPATIBLE REPLACES A T8 LAMP ON ELECTRONIC IS AND RS BALLASTS
- More Info {4}:
- FIVE-YEAR WARRANTY
- More Info {5}:
- IP20 RATING
- More Info {6}:
- SINGLE SLEEVE PACK
- More Info {7}:
- TYPE A LAMP BALLAST
- WATTAGE SELECTABLE:
- NO
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 50W
- NOMINAL LENGTH:
- 48
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EFFICACY:
- 180.00 LPW
- ENCLOSED FIXTURE USE:
- YES
- R9 VALUE:
- 11
- ROMANCE COPY:
- SATCO'S 10-WATT LED T8 IS A VERSATILE CCT SELECTABLE LIGHTING SOLUTION PERFECT FOR A WIDE RANGE OF FIXTURES AND APPLICATIONS. THIS EASY TO INSTALL LOW MAINTENANCE LAMP GIVES YOU THE OPTION BETWEEN THREE COLOR TEMPERATURES: 4000K 5000K...
- SHORT DESCRIPTION:
- 10T8/LED/48/840-850-865/DR
- TITLE 20 COMPLIANT:
- EXEMPT
- TOTAL HARMONIC DISTORTION:
- 20%
- CA PROP-65:
- LEAD
- BULB DIMMABLE:
- YES-DIMMABLE
- EA LENGTH:
- 50
- SHAP CARTON WIDTH:
- 6.5''
- FLOURESCENT EQUIVALENT:
- 30W
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- SURGE PROTECTION:
- BALLAST DEPENDENT
- START TYPE:
- UTILITY
- STYLE:
- UTILITY
- TITLE 24 COMPLIANT:
- NO
- JA8 COMPLIANT:
- NO
