17 Watt 48 Inch T8 LED; 35K/40K/50K CCT Selectable; Ballast Bypass with Battery Backup; G13 Base; 120-277 Volt SATCO NUVO's S11731 T8 lamp with Battery Backup is the logical choice for commercial installations. Providing up to 90-minutes of illumination in the event of a power failure, this lamp is ideal for use where backup lighting is essential. Available in 17W, This lamp is designed to replace our most popular T8 and T12 fluorescent lamps, with the 17W model offering the option of higher lumen output. This new lamp has Increased safety and energy efficiency while reducing maintenance costs with this easy-to-install fluorescent alternative. {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- NO
- BULB HOURS:
- 50000
- BULB KELVIN:
- 3500K/4000K/5000K
- BULB SHAPE:
- T8
- DIAMETER:
- 1.13
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0051
- LENGTH:
- 47.78
- LUMENS:
- 2100L/2300L/2200L
- SHIP WEIGHT:
- 1.19
- VOLTS:
- 120V-277V
- WARRANTY:
- 5-YEARS
- WEIGHT:
- 1.13
- ADDITIONAL INFO:
- 5 WATTS AND 700 LUMENS IN BATTERY BACKUP MODE
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- BEAM SPREAD:
- 140
- BULB ANSI BASE:
- G13
- BULB BASE:
- MEDIUM BI PIN
- BURNING POSITION:
- HORIZONTAL
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- T20 SBCS PENDING
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- CRI:
- 80+
- DIMMING TYPE:
- PHASE CUT
- DLC APPROVED:
- YES
- DLC CLASSIFICATION:
- STANDARD
- DLC ID:
- S-MASCZT
- DLC PRIMARY USE:
- INTERNAL DRIVER/LINE VOLTAGE (UL TYPE B) LAMPS
- ENCLOSURE RATING:
- NOT FOR USE IN FULLY ENCLOSED VAPOR TIGHT FIXTURES
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- PROVIDES UP TO 90 MINUTES OF ILLUMINATION DURING POWER OUTAGES
- FEATURE 2:
- BATTERY ON/OFF SWITCH CONSERVES BATTERY AFTER INSTALLATION
- FEATURE 3:
- INTEGRATED ALUMINUM HEATSINK TO PROMOTE HEAT DISSIPATION
- FEATURE 4:
- FEATURES COLORQUICK TECHNOLOGY ALLOWING FOR EASY SELECTION OF CCT AT INSTALLATION
- FEATURE 5:
- 5 YEAR WARRANTY
- FLUORESCENT EQUIVALENT:
- 32W
- HAS DRIVER:
- YES
- HAS EMERGENCY BATTERY:
- YES
- HOUSING COLOR:
- WHITE
- INDOOR OUTDOOR:
- INDOOR
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES. MAXIMUM MOUNTING HEIGHT: 13 FEET''
- IOT ENABLED:
- NO
- IP RATING:
- IP20
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LAMP FILAMENT:
- LED
- LENS MATERIAL:
- POLYCARBONATE (PC)
- LOCATION RATING:
- DAMP
- MATERIAL:
- ALUMINUM
- NSF APPROVED:
- YES
- OPERATING FREQUENCY:
- 60HZ
- OPERATING TEMP:
- -20C (-4F) TO +45C (+113F)
- PACK TYPE:
- BOX
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LITHIUM_ION_BATTERY
- SHATTER PROOF TEXT:
- YES
- SPECIFICATION NOTES:
- HEIGHT AT SWITCH: 1.30 INCHES WORK TIME AFTER POWER FAILURE: 90 MINUTES BATTERY RECHARGE TIME IS 24 HOURS''
- TECHNOLOGY:
- LED
- TUBE GUARD USE:
- NO
- WATTAGE SELECTABLE:
- NO
- WATTS:
- 17W
- LAMPS:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 307
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 2.05
- WIDTH RANGE:
- 0-15''
- IMAGE INFO:
- ''S11731.JPG:DEFAULT''
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 90W
- SHIP CARTON HEIGHT:
- 1.34''
- SHIP CARTON LENGTH:
- 48.11
- SHIP CARTON WIDTH:
- 2.05''
- NOMINAL LENGTH:
- 48
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- BATTERY CHEMISTRY:
- LITHIUM-ION (LI-ION)
- EFFICACY:
- 123.53/135.29/129.41 LPW
- ENCLOSED FIXTURE USE:
- YES
- JA8 COMPLIANT:
- NO
- LAMP END TYPE:
- SINGLE ENDED
- R9 VALUE:
- 12
- ROMANCE COPY:
- SATCO NUVO'S T8 LAMPS WITH BATTERY BACKUP ARE THE LOGICAL CHOICE FOR COMMERCIAL INSTALLATIONS. PROVIDING UP TO 90-MINUTES OF ILLUMINATION IN THE EVENT OF A POWER FAILURE THESE LAMPS ARE IDEAL FOR USE WHERE BACKUP LIGHTING IS ESSENTIAL. AV...
- SHORT DESCRIPTION:
- 17T8/LED/48-CCT/BB/BP
- TITLE 20 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- <25%
- CA PROP-65:
- LEAD
- EA LENGTH:
- 48.11
- SHAP CARTON WIDTH:
- 2.05''
- FLOURESCENT EQUIVALENT:
- 32W
- CARTON CUBIC FEET:
- 0.0765
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 1KV
- TITLE 24 COMPLIANT:
- NO
- COLOR TEMPRATURE:
- NEUTRAL WHITE TO NATURAL LIGHT
- BULB DIMMABLE:
- BOX
- START TYPE:
- UTILITY
- STYLE:
- UTILITY
- FEATURE 6:
- MEDIUM BI PIN BASE
- LONG DESCRIPTION:
- SATCO NUVO'S S11731 T8 LAMP WITH BATTERY BACKUP IS THE LOGICAL CHOICE FOR COMMERCIAL INSTALLATIONS. PROVIDING UP TO 90-MINUTES OF ILLUMINATION IN THE EVENT OF A POWER FAILURE THIS LAMP IS IDEAL FOR USE WHERE BACKUP LIGHTING IS ESSENTIAL. ...
- ORDER IN MULTIPLES OF:
- 20
- CATEGORY:
- LED
- SUB-CATEGORY:
- LED T8
- COUNTRY OF ORIGIN:
- CHINA
- 4/29/2025 14:
- 21
- FINISH:
- ''FINISH FAMILY'':''WHITE''
- STANDARD STYLE:
- ''WATTS'':''17W''
- 5/2/2025 14:
- 20
- 5/5/2025 21:
- 28
- 5/6/2025 14:
- 20
- 2025-05-07 14:
- 21:05
- HAS CAMERA:
- NO
- HEIGHT:
- 1.34
- HEIGHT RANGE:
- 0-15''
