2 ft. LED; 20 Watt Linear Strip Light; CCT Selectable; White Finish; 120-277 Volt; Microwave Sensor {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- ADDITIONAL INFO:
- OTHER DLC LISTING: S-Q129W0 STANDARD DIRECT LINEAR AMBIENT LUMINAIRES.
- BULB HOURS:
- 50000
- BULB KELVIN:
- NEUTRAL WHITE TO DAYLIGHT
- BULB TYPE:
- LED
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.11.6010
- LENGTH:
- 24
- LUMENS:
- 2735L-2830L
- SHIP CARTON HEIGHT:
- 5.31''
- SHIP CARTON LENGTH:
- 26.1
- SHIP CARTON WIDTH:
- 5.2''
- WARRANTY:
- 5-YEARS
- AMPS:
- 0.167-0.072A
- ANSI BASE:
- INTEGRATED
- BEAM SPREAD:
- 120
- B_U_G_RATING:
- B1-U3-G1
- CA PROP-65:
- LEAD
- CARTON CUBIC FEET:
- 0.4171
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- CRI:
- 80+
- DIMMABLE FUNCTION:
- 0-10V DIMMING BI-LEVEL DIMMABLE
- DLC CLASSIFICATION:
- PREMIUM STANDARD
- DLC PRIMARY USE:
- STAIRWELL AND PASSAGEWAY LUMINAIRES DIRECT LINEAR AMBIENT LUMINAIRES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- CCT SELECTABLE
- FEATURE 2:
- FLICKER FREE DRIVER
- FEATURE 3:
- 0-10V DIMMABLE
- FEATURE 4:
- MULTIPLE MOUNTING OPTIONS
- FEATURE 5:
- DLC PREMIUM
- FEATURE 6:
- INTEGRATED MICROWAVE SENSOR
- FEATURE 7:
- ULTRA SLIM DESIGN
- FLICKER FREE:
- YES
- HAS DRIVER:
- YES
- HID EQUIV:
- 100W-150W
- INCANDESCENT EQUIVALENT:
- 150W-175W
- INDOOR OUTDOOR:
- INDOOR
- IOT ENABLED:
- NO
- IP RATING:
- IP20
- LENS MATERIAL:
- POLYCARBONATE (PC)
- LONG DESCRIPTION:
- THE SATCO NUVO 65-1700 LED 2-FOOT LINEAR STRIP FIXTURE FEATURES AN INTEGRATED MICROWAVE SENSOR FOR ADDED ENERGY EFFICIENCY AND SAVINGS. WITH 3-CCT SELECTABLE OPTIONS - 3500K 4000K 5000K - THE USER CAN TAILOR THE LIGHTING TO THEIR SPECIFI...
- MATERIAL:
- STEEL
- MOUNTING DIAMETER:
- 4.75
- MOUNTING PROCEDURE:
- CEILING/WALL
- OPERATING FREQUENCY:
- 50/60HZ
- OPERATING TEMPRATURE:
- -4F TO +140F (-20C TO +60C)
- PACK TYPE:
- BOX
- PHOTOCELL:
- BI-LEVEL MICROWAVE SENSOR
- POWER FACTOR:
- 0.9
- ROHS COMPLIANT:
- YES
- SAFETY LISTING:
- CULUS - CERTIFIED
- SDS CLASS:
- LED_FIXTURE
- TEMPERATURE (CCT):
- 3500K/4000K/5000K
- WATTAGE SELECTABLE:
- NO
- WEIGHT LB.:
- 1.78
- QUANTITY AVAILABLE AT MANUFACTURER:
- 269
- IMAGE INFO:
- ''65-1700.JPG:DEFAULT''
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 3.27
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 2.95
- WIDTH RANGE:
- 0-15''
- REPLACEABLE LIGHT SOURCE:
- NO
- REPLACES:
- #REF!
- SDS SHEET LINK:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- NEUTRAL WHITE TO DAYLIGHT
- EACH HEIGHT:
- 5.31''
- EACH LENGTH:
- 26.1
- EACH WIDTH:
- 5.2''
- TARIFF CODE:
- 9405.11.6010
- BAA COMPLIANT:
- NO
- BEAM ANGLE:
- 120
- DIMMABLE DOWN TO:
- 100 TO 10 PERCENT
- EACH CUBE:
- 0.4171
- EACH QUANTITY:
- 1
- EFFICACY:
- 136.75/139.13/141.50 LPW
- JA8 COMPLIANT:
- NO
- QUANTITY IN PACK:
- 1
- ROMANCE COPY:
- SATCO NUVO OFFERS LED LINEAR STRIP FIXTURES IN 2 4 AND 8-FOOT SIZES. THESE FIXTURES PROVIDE FLEXIBILITY WITH 3-CCT SELECTABLE OPTIONS - 3500K 4000K AND 5000K - ALLOWING THE USER TO TAILOR THE LIGHTING TO THEIR SPECIFIC NEEDS AND PREFER...
- SHORT DESCRIPTION:
- 2' LINEAR STRIP W/SENSOR
- TITLE 20 COMPLIANT:
- EXEMPT
- TOTAL HARMONIC DISTORTION:
- 13.61%
- STYLE:
- UTILITY
- BULB SHAPE1:
- INTEGRATED LED
- CONNECTION:
- HARDWIRE
- NSF APPROVED:
- NO
- SLOPED CEILING COMPATIBLE:
- YES
- CEILING:
- YES
- TITLE 24 COMPLIANT:
- NO
- SENSOR TYPE:
- MICROWAVE
- ORDER IN MULTIPLES OF:
- 1
- FINISH:
- UNDERCABINET
- STANDARD STYLE:
- LED UNDERCABINET LIGHTS
- CATEGORY:
- LINEAR STRIP
- SUB CATEGORY:
- STRIP FIXTURE
- COUNTRY OF ORIGIN:
- VIETNAM
- 4/29/2025 14:
- 20
- HAS CAMERA:
- NO
- HAS EMERGENCY BATTERY:
- NO
- BEAM ANGLE SELECTABLE:
- NO
- CA PROP-65 STATEMENT:
- WARNING: THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER OR BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION GO TO HTTP://WWW.P65WARNINGS.CA.GOV.
- DEFAULT CCT:
- 4000K
- DEFAULT LUMENS:
- 2735L
- DIMMING TYPE:
- 0-10V DIMMING BI-LEVEL DIMMABLE
- FIELD SELECTABLE:
- NO
- VOLTAGE TEXT:
- RANGE VOLTAGE
