LED Flat Panel Fixture; 40W; 2 ft. x 2 ft.; 5000K; 120-347V {ADDITIONAL FINISH INFORMATION: ''White''}
- status:
- N/A
- BULBS:
- 40W WATT:40W WATT:1
- STYLE:
- Utility
- BULB DIMMABLE:
- 0-10V Dimming Only Use 120-277V or 347V Dimmers only
- BULB HOURS:
- 50000
- BULB SHAPE:
- Integrated LED
- BULB TYPE:
- LED
- HARMONIZED CODES:
- 9405.40.8200
- LENGTH:
- 23.69
- LUMENS:
- 4400L
- SHIP WEIGHT:
- 17
- VOLTAGE:
- 347V
- WARRANTY:
- 5 Year Limited - Fixtures
- ADDITIONAL INFO:
- Pricing Note- Product must be ordered in multiples of 2. Pricing (not shown here) is for one piece even though there are 2 pieces in a case.
- CARTONS PER UNIT:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- COLOR TEMPRATURE:
- Natural Light
- CRI:
- 80
- DLC APPROVED:
- NO
- DLC ID:
- PLN2IA7OJDIE
- LOCATION RATING:
- Damp
- PACK TYPE:
- Bulk
- FINISH:
- WHITE
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- No
- HEIGHT:
- 0.41
- WIDTH:
- 23.69
- Standard Style:
- Transitional
- DIMMABLE:
- Yes-Dimmable
- DIMMABLE FUNCTION:
- 0-10V DIMMING ONLY USE 120-277V OR 347V DIMMERS ONLY
- HEIGHT RANGE:
- 0-15''
- WIDTH RANGE:
- 20-25''
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- QUANTITY AVAILABLE AT MANUFACTURER:
- 14
- QUANTITY AVAILABLE AT MANUFACTURER:
- 0
- ANSI BASE:
- INTEGRATED
- CONNECTION:
- DIRECT WIRED
- DIMMING TYPE:
- 0-10V
- FCC COMPLIANT:
- YES
- FINISH FAMILY:
- WHITE
- FIXTURE SHAPE:
- SQUARE
- FLICKER FREE:
- YES
- INDOOR OUTDOOR:
- INDOOR
- MOUNTING PROCEDURE:
- CEILING
- NUMBER OF LAMPS:
- 1
- OPERATING FREQUENCY:
- 50/60HZ
- ORDER IN MULTIPLES OF:
- 2
- PANEL SIZE:
- 2X2
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 2
- ROHS COMPLIANT:
- YES
- TEMPERATURE (CCT):
- 5000K
- WEIGHT LB.:
- 6.88
- LAMPS:
- YES
- AMPS:
- 0.333-0.115A
- SDS SHEET LINK:
- #REF!
- SDS CLASS:
- LED_FIXTURE
- BULB KELVIN:
- NATURAL LIGHT
- CA PROP-65:
- LEAD
- REPLACEABLE LIGHT SOURCE:
- NO
- SAFETY LISTING:
- CULUS - CERTIFIED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CCT SELECTABLE:
- NO
- WATTAGE SELECTABLE:
- NO
- INCANDESCENT EQUIVALENT:
- 175W
- REPLACES:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- NATURAL LIGHT
- TARIFF CODE:
- 9405.40.8200
- BAA COMPLIANT:
- NO
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EACH QUANTITY:
- 1
- EFFICACY:
- 110.00 LPW
- JA8 COMPLIANT:
- NO
- SHORT DESCRIPTION:
- 2X2 PANEL DLC 4.2 120-347V
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
