Blink Pro - 9W; 5in; LED Fixture; CCT Selectable; Round Shape; White Finish; 120V {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- STYLE:
- UTILITY
- ADDITIONAL INFO:
- UGR - 28.89 SDCM - 464 HI POT - DC-1550V EDGE-LIT - YES
- BULB HOURS:
- 50000
- BULB KELVIN:
- WARM WHITE TO NATURAL LIGHT
- BULB SHAPE:
- INTEGRATED LED
- BULB TYPE:
- LED
- DIAMETER:
- 5
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.11.8020
- LUMENS:
- 700L-780L
- SHIP CARTON HEIGHT:
- 5.2''
- SHIP CARTON LENGTH:
- 5.2
- SHIP CARTON WIDTH:
- 1.81''
- WARRANTY:
- 5 YEAR LIMITED - FIXTURES
- AMPS:
- 0.075A
- ANSI BASE:
- INTEGRATED
- BEAM SPREAD:
- 100
- CA PROP-65:
- LEAD
- CARTON CUBIC FEET:
- 0.0283
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- CALIFORNIA T24 2016 - 2022 JA8 LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- CALIFORNIA T24 LISTED
- CLOSET RATED:
- YES
- CRI:
- 90
- DIMMABLE FUNCTION:
- 120V ONLY
- ES UNIQUE ID:
- ESID-2402966
- FCC COMPLIANT:
- YES
- FINISH FAMILY:
- WHITE
- FIXTURE SHAPE:
- ROUND
- FLICKER FREE:
- NO
- INDOOR OUTDOOR:
- INDOOR
- INSTALLATION NOTES:
- SURFACE MOUNT COMPATIBLE WITH 3IN. & 4IN. J-BOX AND PANCAKE J-BOX WITH ADDITIONAL ACCESSORY
- LENS MATERIAL:
- POLY METHYL METHACRYLATE (PMMA)
- MATERIAL:
- DIE-CAST ALUMINUM
- NEC COMPLIANCE:
- CLOTHES CLOSET CERTIFIED - REG: 410.16 (A)(3) AND 410.16 (C)(5)
- OPERATING FREQUENCY:
- 60HZ
- OPERATING TEMPRATURE:
- -20C (-4F) TO +40C (+104F)
- PACK TYPE:
- BOX
- QUANTITY IN PACK:
- 1
- REPLACEABLE LIGHT SOURCE:
- NO
- ROHS COMPLIANT:
- YES
- SAFETY LISTING:
- CETLUS
- SDS CLASS:
- LED_FIXTURE
- SDS SHEET LINK:
- #REF!
- TEMPERATURE (CCT):
- 2700K/3000K/3500K/4000K/5000K
- WEIGHT LB.:
- 0.59
- QUANTITY AVAILABLE AT MANUFACTURER:
- 572
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 0.67
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 5.00
- WIDTH RANGE:
- 0-15''
- IMAGE INFO:
- ''''
- MOUNTING PROCEDURE:
- CEILING
- SPECIFICATION NOTES:
- OVERALL HEIGHT OF FIXTURE AND DRIVER: 1.59
- POWER FACTOR:
- 0.9
- More Info {1}:
- UGR - 28.89 SDCM - 464 HI POT - DC-1550V EDGE-LIT - YES
- FEATURE 1:
- INTEGRATED LED FEATURING 9 WATTS CCT SELECTABLE FROM WARM TO NATURAL LIGHT 90 CRI
- FEATURE 10:
- EASY INSTALLATION WITH INCLUDED INSTRUCTIONS
- FEATURE 2:
- FIXTURE IS DIMMABLE SELECTABLE FROM 700 TO 780 LUMENS WITH A BEAM SPREAD OF 100
- FEATURE 3:
- 5 INCH DIAMETER X 0.67 INCH HEIGHT''
- FEATURE 5:
- CLOSET RATED WITH ZERO CLEARANCE FROM STORAGE MATERIAL
- FEATURE 6:
- IDEAL FOR CORRIDORS CLOSETS KITCHENS BATHROOMS BEDROOMS INCLUDING OUTDOORS AS THEY ARE WET LOCATION RATED WITH CLOSED CEILING APPLICATIONS
- FEATURE 7:
- RATED FOR 50000 HOURS
- FEATURE 8:
- 5 YEAR WARRANTY
- FEATURE 9:
- VISIT SATCO.COM FOR OPTIONAL ACCESSORIES: 5 INCH ROUND EXTENSION COLLAR WHITE - 25-1700 BLACK - 25-1701 BRONZE - 25-1702
- LONG DESCRIPTION:
- FROM DESIGNER AESTHETICS TO STATE-OF-THE-ART TECHNOLOGY BLINK'S ENERGY STAR CERTIFIED FIXTURES EMBODY THIS CONCEPT ENTIRELY. THE SLEEK LOW-PROFILE STYLE FEATURES DIE-CAST CONSTRUCTION AND IS CCT SELECTABLE WITH FIVE PRESET OPTIONS FROM...
- INCANDESCENT EQUIVALENT:
- 60W
- REPLACES:
- #REF!
- SLOPED CEILING COMPATIBLE:
- YES
- WATTAGE SELECTABLE:
- NO
- CEILING:
- YES
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM WHITE TO NATURAL LIGHT
- EACH HEIGHT:
- 5.2''
- EACH LENGTH:
- 5.2
- EACH WIDTH:
- 1.81''
- TARIFF CODE:
- 9405.11.8020
- BAA COMPLIANT:
- NO
- BEAM ANGLE:
- 100
- DIMMABLE DOWN TO:
- 100 TO 10 PERCENT
- EACH CUBE:
- 0.0283
- EACH QUANTITY:
- 1
- EFFICACY:
- 77.78/82.22/86.67 LPW
- JA8 COMPLIANT:
- YES
- ROMANCE COPY:
- FROM DESIGNER AESTHETICS TO STATE-OF-THE-ART TECHNOLOGY BLINK'S ENERGY STAR CERTIFIED FIXTURES EMBODY THIS CONCEPT ENTIRELY. THE SLEEK LOW-PROFILE STYLE FEATURES DIE-CAST CONSTRUCTION AND IS CCT SELECTABLE WITH FIVE PRESET OPTIONS FROM...
- SHORT DESCRIPTION:
- BLINK 9W LED 5'' RND WHITE
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- YES
- TOTAL HARMONIC DISTORTION:
- <20%
