75 Watt Adjustable Post Top LED; CCT Selectable; 120-347 Volt; Bronze Finish {ADDITIONAL FINISH INFORMATION: ''Bronze''}
- AVAILABLE FOR PURCHASE:
- YES
- ADDITIONAL INFO:
- FOR INTERNATIONAL DARK SKY COMPLIANCE THE FIXTURE CCT MUST BE SET TO 3000K AND INSTALLED IN A DOWNWARD FACING AND LOCKED POSITION
- BULB HOURS:
- 50000
- BULB KELVIN:
- WARM WHITE TO NATURAL LIGHT
- BULB TYPE:
- LED
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.42.6000
- LUMENS:
- 9220L/10100L/9720L
- WARRANTY:
- 5-YEARS
- AMPS:
- 0.625-0.216A
- BEAM SPREAD:
- 90
- CA PROP-65:
- LEAD
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CRI:
- 80+
- DIMMABLE FUNCTION:
- 0-10V DIMMING
- FCC COMPLIANT:
- YES
- FITTER:
- 3 IN.
- IMPACT RATING (IK):
- IK08
- INCANDESCENT EQUIVALENT:
- 175W
- IP RATING:
- IP65
- LENS MATERIAL:
- POLYCARBONATE (PC)
- MATERIAL:
- DIE-CAST ALUMINUM
- OPERATING TEMPRATURE:
- -40F TO +122F (-40C TO +50C)
- PACK TYPE:
- BROWN BOX
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SAFETY LISTING:
- CULUS - CERTIFIED
- SPECIFICATION NOTES:
- POWDER COATED
- TEMPERATURE (CCT):
- 3000K/4000K/5000K
- QUANTITY AVAILABLE AT MANUFACTURER:
- 977
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 20.59
- HEIGHT RANGE:
- 20-25''
- WIDTH:
- 17.91
- WIDTH RANGE:
- 15-20''
- B_U_G_RATING:
- B3-U3-G1
- DLC CLASSIFICATION:
- PREMIUM
- DLC PRIMARY USE:
- OUTDOOR POLE/ARM-MOUNTED DECORATIVE LUMINAIRES
- WEIGHT LB.:
- 18.5
- SHIP CARTON HEIGHT:
- 7.09''
- SHIP CARTON LENGTH:
- 28.74
- SHIP CARTON WIDTH:
- 20.28''
- CARTON CUBIC FEET:
- 2.3914
- FEATURE 1:
- 0-90 DEGREE ADJUSTABLE ILLUMINATION
- FEATURE 2:
- 3K/4K/5K COLOR SELECTABLE
- FEATURE 3:
- IK08 IMPACT RATED
- FEATURE 4:
- IP65 RATED
- FEATURE 6:
- DLC 5.1 LISTED
- INCLUDES:
- 3 INCH FITTER
- LONG DESCRIPTION:
- SATCO NUVO'S 65-892 LED ADJUSTABLE POST TOP EXTERIOR FIXTURE OFFERS A SLEEK CONTEMPORARY DESIGN IDEAL FOR GENERAL LIGHTING ENVIRONMENTS REQUIRING A HIGHLY EFFICIENT ARCHITECTURAL LIGHT SOURCE WITH PRECISE CONTROL. COLOR SELECTABLE CHOICES...
- MOUNTING PROCEDURE:
- POST
- STYLE:
- COMMERCIAL
- OPERATING FREQUENCY:
- 50/60HZ
- POWER FACTOR:
- >0.9
- SDS CLASS:
- LED_FIXTURE
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- WATTAGE SELECTABLE:
- NO
- IMAGE INFO:
- ''65-892.JPG:DEFAULT''
- STANDARD STYLE:
- COMMERCIAL
- REPLACEABLE LIGHT SOURCE:
- NO
- REPLACES:
- #REF!
- SDS SHEET LINK:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM WHITE TO NATURAL LIGHT
- EACH HEIGHT:
- 7.09''
- EACH LENGTH:
- 28.74
- EACH WIDTH:
- 20.28''
- TARIFF CODE:
- 9405.42.6000
- BAA COMPLIANT:
- NO
- BEAM ANGLE:
- 90
- EACH CUBE:
- 2.3914
- EACH QUANTITY:
- 1
- EFFICACY:
- 122.93/134.67/129.60 LPW
- JA8 COMPLIANT:
- NO
- R9 VALUE:
- 8
- ROMANCE COPY:
- SATCO NUVO'S LED ADJUSTABLE POST TOP EXTERIOR FIXTURES OFFER A SLEEK CONTEMPORARY DESIGN IDEAL FOR COMMERCIAL PATHWAYS PARKS CAMPUSES AND GENERAL AREA LIGHTING ENVIRONMENTS REQUIRING A HIGHLY EFFICIENT ARCHITECTURAL LIGHT SOURCE WITH P...
- SHORT DESCRIPTION:
- LED 75W POST TOP CCT SELECT
- TITLE 20 COMPLIANT:
- EXEMPT
- TOTAL HARMONIC DISTORTION:
- 15%
- BULB SHAPE1:
- INTEGRATED LED
- ANSI BASE:
- INTEGRATED
- INDOOR OUTDOOR:
- OUTDOOR
- ORDER IN MULTIPLES OF:
- 1
- TITLE 24 COMPLIANT:
- NO
- FINISH:
- EXTERIOR
- CATEGORY:
- OUTDOOR
- SUB CATEGORY:
- POST
- COUNTRY OF ORIGIN:
- VIETNAM
- FEATURE 5:
- BRONZE POWDER COATED FINISH
- 5/2/2025 14:
- 18
- 5/6/2025 21:
- 27
- HAS CAMERA:
- NO
- HAS EMERGENCY BATTERY:
- NO
- IOT ENABLED:
- NO
- BEAM ANGLE SELECTABLE:
- NO
- CA PROP-65 STATEMENT:
- WARNING: THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER OR BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE INFORMATION GO TO HTTP://WWW.P65WARNINGS.CA.GOV.
- DEFAULT CCT:
- 4000K
- DEFAULT LUMENS:
- 9720L
- DIMMING TYPE:
- 0-10V DIMMING
- FIELD SELECTABLE:
- NO
- VOLTAGE TEXT:
- AC ONLY RANGE VOLTAGE
