75 Watt Adjustable Post Top LED; CCT Selectable; 120-347 Volt {ADDITIONAL FINISH INFORMATION: ''Bronze''}
- AVAILABLE FOR PURCHASE:
- YES
- ADDITIONAL INFO:
- FOR INTERNATIONAL DARK SKY COMPLIANCE THE FIXTURE CCT MUST BE SET TO 3000K AND INSTALLED IN A DOWNWARD FACING AND LOCKED POSITION
- BULB HOURS:
- 50000
- BULB KELVIN:
- WARM WHITE TO NATURAL LIGHT
- BULB TYPE:
- LED
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.42.6000
- LUMENS:
- 9220L/10100L/9720L
- WARRANTY:
- 5 YEAR LIMITED - FIXTURES
- AMPS:
- 0.625-0.216A
- BEAM SPREAD:
- 90
- CA PROP-65:
- LEAD
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CRI:
- 80
- DIMMABLE FUNCTION:
- 0-10V DIMMING
- FCC COMPLIANT:
- YES
- FITTER:
- 3 IN.
- IMPACT RATING (IK):
- IK08
- INCANDESCENT EQUIVALENT:
- 175W
- IP RATING:
- IP65
- LENS MATERIAL:
- POLYCARBONATE (PC)
- MATERIAL:
- DIE-CAST ALUMINUM
- OPERATING TEMPRATURE:
- -40C (-40F) TO +50C (+122F)
- PACK TYPE:
- BROWN BOX
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SAFETY LISTING:
- CULUS
- SPECIFICATION NOTES:
- POWDER COATED
- TEMPERATURE (CCT):
- 3000K/4000K/5000K
- QUANTITY AVAILABLE AT MANUFACTURER:
- 57
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- HEIGHT:
- 20.59
- HEIGHT RANGE:
- 20-25''
- WIDTH:
- 17.91
- WIDTH RANGE:
- 15-20''
- B_U_G_RATING:
- B3-U3-G1
- DLC CLASSIFICATION:
- PREMIUM
- DLC PRIMARY USE:
- OUTDOOR POLE/ARM-MOUNTED DECORATIVE LUMINAIRES
- WEIGHT LB.:
- 18.5
- SHIP CARTON HEIGHT:
- 7.09''
- SHIP CARTON LENGTH:
- 28.74
- SHIP CARTON WIDTH:
- 20.28''
- CARTON CUBIC FEET:
- 2.3914
- FEATURE 1:
- 0-90 DEGREE ADJUSTABLE ILLUMINATION
- FEATURE 2:
- 3K/4K/5K COLOR SELECTABLE
- FEATURE 3:
- IK08 IMPACT RATED
- FEATURE 4:
- IP65 RATED
- FEATURE 6:
- DLC 5.1 LISTED
- INCLUDES:
- 3 INCH FITTER
- LONG DESCRIPTION:
- SATCO
- MOUNTING PROCEDURE:
- POST
- STYLE:
- COMMERCIAL
- OPERATING FREQUENCY:
- 50/60HZ
- POWER FACTOR:
- >0.9
- SDS CLASS:
- LED_FIXTURE
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- WATTAGE SELECTABLE:
- NO
- IMAGE INFO:
- ''''
- STANDARD STYLE:
- COMMERCIAL
- REPLACEABLE LIGHT SOURCE:
- NO
- REPLACES:
- #REF!
- SDS SHEET LINK:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM WHITE TO NATURAL LIGHT
- EACH HEIGHT:
- 7.09''
- EACH LENGTH:
- 28.74
- EACH WIDTH:
- 20.28''
- TARIFF CODE:
- 9405.42.6000
- BAA COMPLIANT:
- NO
- BEAM ANGLE:
- 90
- EACH CUBE:
- 2.3914
- EACH QUANTITY:
- 1
- EFFICACY:
- 122.93/134.67/129.60 LPW
- JA8 COMPLIANT:
- NO
- R9 VALUE:
- 8
- ROMANCE COPY:
- SATCO
- SHORT DESCRIPTION:
- LED 75W POST TOP CCT SELECT
- TITLE 20 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- 15%
