Touch On/Off and Occupancy Sensor Controller Intelligent motion and touch switch control of luminaires based on occupancy, compatible with wide range of WAC Lighting low voltage LED lighting luminaires. Can be used with any WAC Lighting 12V or 24V electronic low voltage system, including Button Lights, InvisiLED® Tape light, Line, and Straight edge. Programmed with three functions, TOUCH and SENSOR To activate both motion sensor and touch switch. TOUCH Only touch switch, inactivate motion sensor. SENSOR Only motion sensor, inactivate touch switch. Built-in adjustable timer on motion sensor allows automatic shut off after the sensor covered area is vacated. Maximum time delay is 20 minutes (20MIN), minimum is 10 seconds (10S). Motion sensor supplied with 18ft wire and touch panel supplied with 8ft wire. May be cut to desired length. Lengthening of wire is not recommended as will decrease sensitivity. Two different mounting options (screw or double sided tape mounting) for all under cabinet application included. Choose appropriate mounting option for rough, smooth and curved surfaces. • Designed for indoor under cabinet application. {ADDITIONAL FINISH INFORMATION: ''black''}
- STYLE:
- Functional
- BULB DIMMABLE:
- Yes
- LENGTH:
- 5
- SHIP CARTON HEIGHT:
- 3.543''
- SHIP CARTON LENGTH:
- 6.496
- SHIP CARTON WIDTH:
- 4.921''
- VOLTAGE:
- 12/24 VAC/DC
- WARRANTY:
- 5 Year Functional 2 Year Finish
- WEIGHT:
- 0.957
- BRAND:
- WAC Lighting
- BULBS INCLUDED:
- No
- COLLECTION:
- INVISILED
- COMPLETE SYSTEM:
- No
- LTL:
- No
- MAIN TYPE:
- Accessories
- MANUFACTURERS LINK:
- HTTPS://WWW.WACLIGHTING.COM/PRODUCT/INVISILED/
- PRODUCT SUB-TYPE:
- Occupancy Sensor
- PRODUCT TYPE:
- Transformer
- RANK:
- 1
- RELEASE:
- 41640
- SAFETY RATING:
- ETL cETL
- TOTAL WATTAGE:
- 100
- HEIGHT:
- 1.00
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 1.38
- WIDTH RANGE:
- 0-15''
- FINISH:
- BLACK
- ON DISPLAY IN SHOWROOM:
- No
- IN STOCK IN SHOWROOM:
- NO
- Standard Style:
- Traditional
- AVAILABLE FOR PURCHASE:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 179
