LED Vapor Proof with Occupancy Sensor; 29W; 100-277V {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- YES
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- STYLE:
- UTILITY
- BULB HOURS:
- 50000
- BULB SHAPE:
- INTEGRATED LED
- BULB TYPE:
- LED
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.42.6000
- LENGTH:
- 50
- LUMENS:
- 3400L
- SHIP CARTON HEIGHT:
- 5.71''
- SHIP CARTON LENGTH:
- 52.36
- SHIP CARTON WIDTH:
- 7.09''
- SHIP WEIGHT:
- 6.83
- WARRANTY:
- 5 YEAR LIMITED - FIXTURES
- ANSI BASE:
- INTEGRATED
- CARTON CUBIC FEET:
- 1.2267
- CARTONS PER UNIT:
- 1
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- COLOR TEMPRATURE:
- NATURAL LIGHT
- CONNECTION:
- DIRECT WIRED
- CRI:
- 80
- DIMMABLE FUNCTION:
- 0-10V DIMMING ONLY
- DIMMING TYPE:
- 0-10V
- DLC APPROVED:
- NO
- FCC COMPLIANT:
- YES
- FINISH FAMILY:
- WHITE
- IP RATING:
- IP65
- LOCATION RATING:
- WET
- MATERIAL:
- PLASTIC
- MOUNTING PROCEDURE:
- CEILING
- NUMBER OF LAMPS:
- 1
- OPERATING TEMP:
- -30C (-22F) TO +55C (+131F)
- PACK TYPE:
- BOX
- PHOTOCELL:
- HAS OCCUPANCY SENSOR
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- TEMPERATURE (CCT):
- 5000K
- WEIGHT LB.:
- 6.49
- LAMPS:
- YES
- QUANTITY AVAILABLE AT MANUFACTURER:
- 400
- FINISH:
- WHITE
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- STANDARD STYLE:
- TRADITIONAL
- HEIGHT:
- 2.94
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 4.53
- WIDTH RANGE:
- 0-15''
- AMPS:
- 0.290-0.105A
- SDS SHEET LINK:
- #REF!
- SDS CLASS:
- LED_FIXTURE
- BULB KELVIN:
- NATURAL LIGHT
- CA PROP-65:
- LEAD
- CEC WEB TEXT:
- LAWFUL FOR SALE
- OPERATING TEMPRATURE:
- -30C (-22F) TO +55C (+131F)
- REPLACEABLE LIGHT SOURCE:
- NO
- SAFETY LISTING:
- CETLUS - LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CCT SELECTABLE:
- NO
- WATTAGE SELECTABLE:
- NO
- INCANDESCENT EQUIVALENT:
- 200W
- REPLACES:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- NATURAL LIGHT
- EACH HEIGHT:
- 5.71''
- EACH LENGTH:
- 52.36
- EACH WIDTH:
- 7.09''
- TARIFF CODE:
- 9405.42.6000
- BAA COMPLIANT:
- NO
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EACH CUBE:
- 1.2267
- EACH QUANTITY:
- 1
- EFFICACY:
- 117.24 LPW
- JA8 COMPLIANT:
- NO
- SENSOR DETECTION RANGE:
- 16M X 15M MAXIMUM
- SENSOR FIELD OF VIEW:
- 30 DEG TO 150 DEG
- SENSOR MOUNTING HEIGHT:
- 6M MAXIMUM''
- SENSOR OPERATING TEMPERATURE:
- -20C (-4F) TO A MAXIMUM OF 60C (+140F)
- SENSOR OPERATION:
- INTERGRATED MICROWAVE SENSOR
- SENSOR TIME DELAY:
- 5S 30S 1MIN 5MIN 10MIN 20MIN 30MIN
- SHORT DESCRIPTION:
- 29W VAPOR PROOF W/OCC SENSOR
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
