54 Watt LED HID Replacement; CCT Selectable; Type B; Ballast Bypass; Mogul Extended Base; 277-480 Volt; ColorQuick Technology {ADDITIONAL FINISH INFORMATION: ''White''}
- AVAILABLE FOR PURCHASE:
- NO
- QUANTITY AVAILABLE AT MANUFACTURER:
- UNKNOWN
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 3.35
- WIDTH RANGE:
- 0-15''
- BULB HOURS:
- 50000
- BULB KELVIN:
- 3000K/4000K/5000K
- BULB SHAPE:
- CORNCOB
- DIAMETER:
- 3.35
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0091
- LENGTH:
- 9.53
- LUMENS:
- 7020L/7560L/7290L
- SHIP CARTON HEIGHT:
- 3.66''
- SHIP CARTON LENGTH:
- 10.98
- SHIP CARTON WIDTH:
- 3.66''
- SHIP WEIGHT:
- 1.92
- VOLTS:
- 277V-480V
- WARRANTY:
- 5-YEARS
- WEIGHT:
- 1.65
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- BEAM SPREAD:
- 300
- BULB ANSI BASE:
- EX39
- BULB BASE:
- MOGUL EXTENDED
- BULB FINISH:
- WHITE
- BURNING POSITION:
- UNIVERSAL
- CARTON CUBIC FEET:
- 0.0851
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- EXEMPT - BASE NOT REGULATED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- WARM TO COOL WHITE
- CRI:
- 80+
- DIMMABLE FUNCTION:
- ONLY DIMMABLE VIA WIFI MODULE 80-954 (AVAILABLE FOR PURCHASE) AND VIA THE STARFISH APP
- DLC APPROVED:
- YES
- DLC CLASSIFICATION:
- STANDARD
- DLC ID:
- S-1ESYVO
- DLC PRIMARY USE:
- REPLACEMENT LAMPS FOR OUTDOOR POLE/ARM-MOUNTED DECORATIVE LUMINAIRES (TYPE B)
- ENCLOSURE RATING:
- ENCLOSED RATED LAMP
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- MOL: 9.53 INCHES MOD: 3.35 INCHES
- FEATURE 2:
- CORNCOB SHAPE
- FEATURE 3:
- WHITE FINISH
- FEATURE 4:
- MOGUL EXTENDED BASE
- FEATURE 5:
- 300 DEGREE BEAM SPREAD
- FEATURE 6:
- RATED FOR 50000 HOURS
- FEATURE 7:
- CCT SELECTABLE
- FEATURE 8:
- 5 YEAR LIMITED WARRANTY
- FEATURE 9:
- DAMP RATED FOR INDOOR AND OUTDOOR USE
- HID EQUIVALENT:
- 250W
- HOUSING COLOR:
- DARK GRAY
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- IOT ENABLED:
- NO
- IP RATING:
- IP64
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LAMP FILAMENT:
- LED
- LENS:
- YES
- LENS MATERIAL:
- PLASTIC
- LOCATION RATING:
- DAMP
- LONG DESCRIPTION:
- SATCO NUVO'S S23166 54 WATT LED LAMP IS THE LAMP OF CHOICE FOR LARGE SCALE APPLICATIONS. ILLUMINATE GYMNASIUMS WAREHOUSES OR ANY OTHER VENUE WITH HIGH CEILINGS REQUIRING SUPERIOR LIGHT OUTPUT. THIS CCT SELECTABLE LAMP DELIVERS 50000 HOU...
- MATERIAL:
- ALUMINUM / POLYCARBONATE (PC)
- MINIMUM COMPARTMENT SIZE:
- LENGTH: 7.87 IN. WIDTH: 7.87 IN.''
- NSF APPROVED:
- NO
- OPERATING FREQUENCY:
- 50/60HZ
- OPERATING TEMP:
- -30C (-22F) TO +45C (+113F)
- PACK TYPE:
- BOX
- PHOTOCELL:
- OPTIONAL
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- TECHNOLOGY:
- LED
- WATTAGE SELECTABLE:
- NO
- WATTS:
- 54W
- LAMPS:
- YES
- IMAGE INFO:
- ''S23166.JPG:DEFAULT''
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 4KV
- DIMMING TYPE:
- SMART-STARFISH APP THROUGH WIFI MODULE ONLY
- More Info {1}:
- 300 DEGREE BEAM SPREAD
- More Info {2}:
- 5 YEAR LIMITED WARRANTY
- More Info {3}:
- CCT SELECTABLE
- More Info {4}:
- CORNCOB SHAPE
- More Info {5}:
- DAMP RATED FOR INDOOR AND OUTDOOR USE
- More Info {6}:
- MOGUL EXTENDED BASE
- More Info {7}:
- MOL: 9.53 INCHES MOD: 3.35 INCHES
- More Info {8}:
- RATED FOR 50000 HOURS
- ORDER IN MULTIPLES OF:
- 1
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 200W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EFFICACY:
- 130.00/140.00/135.00 LPW
- ENCLOSED FIXTURE USE:
- YES
- R9 VALUE:
- 10
- ROMANCE COPY:
- SATCO NUVO'S 54 WATT LED LAMP IS THE LAMP OF CHOICE FOR LARGE SCALE APPLICATIONS. ILLUMINATE GYMNASIUMS WAREHOUSES OR ANY OTHER VENUE WITH HIGH CEILINGS REQUIRING SUPERIOR LIGHT OUTPUT. THIS CCT SELECTABLE LAMP DELIVERS 50000 HOURS OF C...
- SHORT DESCRIPTION:
- 54W/LED/CCT/277-480V/EX39
- STYLE:
- UTILITY
- TITLE 20 COMPLIANT:
- EXEMPT
- TOTAL HARMONIC DISTORTION:
- 8.90%
- CA PROP-65:
- LEAD
- BULB DIMMABLE:
- YES-DIMMABLE
- EA LENGTH:
- 10.98
- SHAP CARTON WIDTH:
- 3.66''
- INSTALLATION NOTES:
- NOT FOR USE IN VAPOR TIGHT FIXTURES.
- TITLE 24 COMPLIANT:
- NO
- JA8 COMPLIANT:
- NO
- START TYPE:
- UTILITY
- FINISH:
- LIGHT BULBS
- STANDARD STYLE:
- LED BULBS
- CATEGORY:
- LED
- SUB-CATEGORY:
- HID REPLACEMENTS
- COUNTRY OF ORIGIN:
- CHINA
- 5/2/2025 21:
- 28
- HAS CAMERA:
- NO
- HAS EMERGENCY BATTERY:
- NO
