36 Watt LED HID Replacement; CCT Selectable; Medium Base; 277-480 Volt; ColorQuick Technology
- AVAILABLE FOR PURCHASE:
- NO
- QUANTITY AVAILABLE AT MANUFACTURER:
- 788
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- WIDTH:
- 3.35
- WIDTH RANGE:
- 0-15''
- BULB HOURS:
- 50000
- BULB KELVIN:
- 3000K/4000K/5000K
- BULB SHAPE:
- CORNCOB
- DIAMETER:
- 3.35
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 8539.52.0091
- LENGTH:
- 7.73
- LUMENS:
- 4680L/5040L/4860L
- SHIP CARTON HEIGHT:
- 3.66''
- SHIP CARTON LENGTH:
- 9.800000000000001
- SHIP CARTON WIDTH:
- 3.66''
- SHIP WEIGHT:
- 1.63
- VOLTS:
- 277V-480V
- WARRANTY:
- 5 YEAR LIMITED - HI-PRO
- WEIGHT:
- 1.4
- BALLAST BYPASS DIRECT:
- BALLAST BYPASS
- BALLASTING REQUIREMENTS:
- BALLAST BYPASS
- BEAM SPREAD:
- 300
- BULB ANSI BASE:
- E26
- BULB BASE:
- MEDIUM
- BULB FINISH:
- WHITE
- BURNING POSITION:
- UNIVERSAL
- CARTON CUBIC FEET:
- 0.076
- CARTONS PER UNIT:
- 1
- CCT SELECTABLE:
- YES
- CEC:
- EXEMPT - >2600 LUMENS
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- CEC WEB TEXT:
- LAWFUL FOR SALE
- COLOR TEMPRATURE:
- WARM TO COOL WHITE
- CRI:
- 80
- DIMMABLE FUNCTION:
- ONLY DIMMABLE VIA SENSOR PORT
- ENCLOSURE RATING:
- ENCLOSED RATED LAMP
- ENCLOSURE RATING1:
- YES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- MOL: 7.73 INCHES MOD: 3.35 INCHES
- FEATURE 2:
- CORNCOB SHAPE
- FEATURE 3:
- WHITE FINISH
- FEATURE 4:
- MEDIUM BASE
- FEATURE 5:
- 300 DEGREE BEAM SPREAD
- FEATURE 6:
- RATED FOR 50000 HOURS
- FEATURE 7:
- CCT SELECTABLE
- FEATURE 8:
- 5 YEAR LIMITED WARRANTY
- FEATURE 9:
- DAMP RATED FOR INDOOR AND OUTDOOR USE
- HID EQUIVALENT:
- 175W
- HOUSING COLOR:
- DARK GRAY
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- IOT ENABLED:
- NO
- IP RATING:
- IP64
- LAMP BALLAST TYPE A/B/C:
- TYPE B
- LAMP FILAMENT:
- LED
- LENS:
- YES
- LENS MATERIAL:
- PLASTIC
- LOCATION RATING:
- DAMP
- LONG DESCRIPTION:
- SATCO'S S23162 36 WATT CORNCOB LAMP IS THE LAMP OF CHOICE FOR LARGE SCALE APPLICATIONS. ILLUMINATE GYMNASIUMS WAREHOUSES OR ANY OTHER VENUE WITH HIGH CEILINGS REQUIRING SUPERIOR LIGHT OUTPUT. THIS CCT SELECTABLE LAMP DELIVERS 50000 HOUR...
- MATERIAL:
- ALUMINUM / POLYCARBONATE (PC)
- MINIMUM COMPARTMENT SIZE:
- LENGTH: 10.55 IN. WIDTH: 8.00 IN. HEIGHT: 8.00 IN.''
- NSF APPROVED:
- NO
- OPERATING FREQUENCY:
- 50/60HZ
- OPERATING TEMP:
- -30C (-22F) TO +45C (+113F)
- PACK TYPE:
- BOX
- PHOTOCELL:
- OPTIONAL
- POWER FACTOR:
- 0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_LAMP
- TECHNOLOGY:
- LED
- WATTAGE SELECTABLE:
- NO
- WATTS:
- 36W
- LAMPS:
- YES
- IMAGE INFO:
- ''''
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 4KV
- DIMMING TYPE:
- SMART-STARFISH APP ONLY
- More Info {1}:
- 300 DEGREE BEAM SPREAD
- More Info {2}:
- 5 YEAR LIMITED WARRANTY
- More Info {3}:
- CCT SELECTABLE
- More Info {4}:
- CORNCOB SHAPE
- More Info {5}:
- DAMP RATED FOR INDOOR AND OUTDOOR USE
- More Info {6}:
- MEDIUM BASE
- More Info {7}:
- MOL: 7.73 INCHES MOD: 3.35 INCHES
- More Info {8}:
- RATED FOR 50000 HOURS
- DLC APPROVED:
- NO
- ORDER IN MULTIPLES OF:
- 1
- BAA COMPLIANT:
- NO
- INCANDESCENT EQUIVALENT:
- 125W
- 3-WAY:
- #REF!
- MAX. DIAMETER:
- #REF!
- SDS SHEET LINK:
- #REF!
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EFFICACY:
- 130.00/140.00/135.00 LPW
- ENCLOSED FIXTURE USE:
- YES
- R9 VALUE:
- 11
- ROMANCE COPY:
- SATCO'S 36 WATT CORNCOB LAMP IS THE LAMP OF CHOICE FOR LARGE SCALE APPLICATIONS. ILLUMINATE GYMNASIUMS WAREHOUSES OR ANY OTHER VENUE WITH HIGH CEILINGS REQUIRING SUPERIOR LIGHT OUTPUT. THIS CCT SELECTABLE LAMP DELIVERS 50000 HOURS OF CL...
- SHORT DESCRIPTION:
- 36W/LED/CCT/277-480V/E26
- STYLE:
- UTILITY
- TITLE 20 COMPLIANT:
- NO
- CA PROP-65:
- LEAD
- BULB DIMMABLE:
- YES-DIMMABLE
- EA LENGTH:
- 9.800000000000001
- SHAP CARTON WIDTH:
- 3.66''
