Emergency LED Cutoff Wall Pack; CCT Selectable 3K/4K/5K; Wattage Adjustable; Bypassable Photocell; 120-277 Volt {ADDITIONAL FINISH INFORMATION: ''Bronze''}
- AVAILABLE FOR PURCHASE:
- NO
- REQUIRED (NOT INCLUDED):
- 1 INTEGRATED BULBS
- BULB HOURS:
- 50000
- BULB SHAPE:
- INTEGRATED LED
- BULB TYPE:
- LED
- DIMMABLE:
- YES-DIMMABLE
- HARMONIZED CODES:
- 9405.42.6000
- LUMENS:
- 3915L-8400L
- SHIP CARTON HEIGHT:
- 12.6''
- SHIP CARTON LENGTH:
- 15.75
- SHIP CARTON WIDTH:
- 11.81''
- SHIP WEIGHT:
- 11.24
- WARRANTY:
- 5 YEAR LIMITED - FIXTURES
- CARTON CUBIC FEET:
- 1.3563
- CARTONS PER UNIT:
- 1
- COLOR TEMPRATURE:
- WARM TO COOL WHITE
- CRI:
- 80
- DIMMABLE FUNCTION:
- 0-10V DIMMING ONLY
- IP RATING:
- IP65
- LOCATION RATING:
- WET
- OPERATING TEMP:
- -40C (-40F) TO +50C (+122F)
- PACK TYPE:
- BOX
- PHOTOCELL:
- YES - BYPASSABLE
- SURGE PROTECTION:
- BUILT-IN SURGE PROTECTION - 10KV
- QUANTITY AVAILABLE AT MANUFACTURER:
- 5
- LOCAL_ON_DISPLAY:
- 0
- ON DISPLAY IN SHOWROOM:
- No
- LOCAL_COUNT_ON_DISPLAY:
- 0
- LOCAL_SALE:
- 0
- LOCAL_COUNT_SALE:
- 0
- LOCAL_IN_STOCK:
- 0
- IN STOCK IN SHOWROOM:
- No
- LOCAL_COUNT-IN_STOCK:
- 0
- LOCAL_CLEARANCE:
- 0
- LOCAL_COUNT_CLEARANCE:
- 0
- DLC APPROVED:
- YES
- DLC ID:
- S-LABY1P
- STYLE:
- TRADITIONAL
- EXTENDS:
- 9.33
- ANSI BASE:
- INTEGRATED
- BEAM ANGLE:
- 110
- B_U_G_RATING:
- B2-U3-G3
- CCT SELECTABLE:
- YES
- CEC:
- T20 EXEMPT - FIXTURES NOT REGULATED
- DIMMING TYPE:
- 0-10V
- DLC CLASSIFICATION:
- PREMIUM
- DLC PRIMARY USE:
- OUTDOOR NON-CUTOFF AND SEMI-CUTOFF WALL-MOUNTED AREA LUMINAIRES
- FCC COMPLIANT:
- YES
- FEATURE 1:
- MAINTENANCE FREE - NO BULB TO CHANGE
- FEATURE 10:
- CONSISTENT EVEN LIGHT DISTRIBUTION
- FEATURE 2:
- INTEGRATED BY-PASSABLE PHOTOCELL
- FEATURE 3:
- BUILT-IN SURGE PROTECTION - 10KV
- FEATURE 4:
- WATTAGE SELECTABLE 29W/40W/60W
- FEATURE 5:
- 50000 HOURS LONG LIFE
- FEATURE 6:
- DLC PREMIUM
- FEATURE 7:
- IP65 RUGGED ALL WEATHER DURABILITY
- FEATURE 8:
- CCT SELECTABLE 3000K/4000K/5000K
- FEATURE 9:
- BATTERY MODE 16W/1120 LUMENS/90 MIN. RUN TIME
- FINISH FAMILY:
- BRONZE
- HAS EMERGENCY BATTERY:
- YES
- HID EQUIV:
- 75W-175W
- INDOOR OUTDOOR:
- INDOOR OUTDOOR
- IOT ENABLED:
- NO
- LENS MATERIAL:
- GLASS
- LONG DESCRIPTION:
- INTRODUCING 65-762 SATCO
- MATERIAL:
- DIE-CAST ALUMINUM
- MOUNTING PROCEDURE:
- WALL
- POWER FACTOR:
- >0.9
- QUANTITY IN PACK:
- 1
- ROHS COMPLIANT:
- YES
- SDS CLASS:
- LED_FIXTURE
- TEMPERATURE (CCT):
- 3000K/4000K/5000K
- WATTAGE SELECTABLE:
- YES
- WEIGHT LB.:
- 10.5
- HEIGHT:
- 9.83
- HEIGHT RANGE:
- 0-15''
- WIDTH:
- 14.26
- AMPS:
- 0.242-0.105/0.333-0.144/0.500-0.217A
- SDS SHEET LINK:
- #REF!
- NUMBER OF LAMPS:
- 1
- LAMPS:
- YES
- BULB KELVIN:
- WARM TO COOL WHITE
- BEAM SPREAD:
- 110
- CA PROP-65:
- LEAD
- CEC WEB TEXT:
- LAWFUL FOR SALE
- INCANDESCENT EQUIVALENT:
- 200W-500W
- OPERATING TEMPRATURE:
- -40C (-40F) TO +50C (+122F)
- REPLACEABLE LIGHT SOURCE:
- NO
- SAFETY LISTING:
- CULUS - LISTED
- CEC TERSE:
- LAWFUL FOR SALE IN CALIFORNIA
- IMAGE INFO:
- ''''
- STANDARD STYLE:
- TRADITIONAL
- CONNECTION:
- HARDWIRE
- OPERATING FREQUENCY:
- 50HZ
- REPLACES:
- #REF!
- AVG RATED HOURS:
- 50000
- BULB SHAPE1:
- INTEGRATED LED
- BULB TYPE1:
- LED
- COLOR TEMPERATURE:
- WARM TO COOL WHITE
- EACH HEIGHT:
- 12.6''
- EACH LENGTH:
- 15.75
- EACH WIDTH:
- 11.81''
- TARIFF CODE:
- 9405.42.6000
- BAA COMPLIANT:
- NO
- BATTERY CHEMISTRY:
- LITHIUM-ION (LI-ION)
- DIMMABLE DOWN TO:
- 100 TO 20 PERCENT
- EACH CUBE:
- 1.3563
- EACH QUANTITY:
- 1
- EFFICACY:
- 135.00/153.94/140.00 LPW
- JA8 COMPLIANT:
- NO
- ROMANCE COPY:
- INTRODUCING SATCO
- SHORT DESCRIPTION:
- EM CUTOFF WALL PACK CCT&WATT
- TITLE 20 COMPLIANT:
- NO
- TITLE 24 COMPLIANT:
- NO
- TOTAL HARMONIC DISTORTION:
- <20%
- WALL:
- YES
